| П-п | Арт | Название |
|---|---|---|
| 1 | Front cover | |
| 2 | Circlip | |
| 3 | Washer | |
| 4 | Slider | |
| 5 | Spring | |
| 6 | Cylinder case | |
| 7 | Bolt | |
| 8 | Spring washer | |
| 9 | Flat washer | |
| 10 | 0 ring | |
| 11 | Guard ring sleeve | |
| 12 | Steel ball | |
| 13 | 0 Ring | |
| 14 | Second striker | |
| 15 | 0 ring | |
| 16 | Ram | |
| 17 | Circlip | |
| 18 | Grease seal | |
| 19 | Big washer | |
| 20 | Ball bearing | |
| 21 | Steel ball | |
| 22 | Cylinder | |
| 23 | Pin | |
| 24 | Circlip | |
| 25 | Big bevel gear | |
| 26 | Seal strip | |
| 27 | Piston pin | |
| 28 | Piston | |
| 29 | Connecting rod | |
| 30 | Needel bearing | |
| 31 | Rubber ring | |
| 32 | Busing block | |
| 33 | 0 ring | |
| 34 | Locating washer | |
| 35 | Circlip | |
| 36 | Oil bearing | |
| 37 | Crank shaft case | |
| 38 | Grease cover | |
| 39 | 0 ring | |
| 40 | Small bevel gear | |
| 41 | Pin | |
| 42 | Ball bearing | |
| 43 | Washer | |
| 44 | Needle bearing | |
| 45 | Core | |
| 46 | Spring | |
| 47 | Steel ball | |
| 48 | Second gear | |
| 49 | Circlip | |
| 50 | Washer | |
| 51 | Circlip | |
| 52 | Clutch | |
| 53 | Disc spring | |
| 54 | Washer | |
| 55 | Ball bearing | |
| 56 | Crank shaft | |
| 57 | Steel ball | |
| 58 | Ball bearing | |
| 59 | Circlip | |
| 60 | Circlip | |
| 61 | First gear | |
| 62 | Spring | |
| 63 | Shore | |
| 64 | Wearing ring | |
| 65 | Needle bearing | |
| 66 | Screw | |
| 67 | Lock plate | |
| 68 | Screw | |
| 69 | Stop plate | |
| 70 | Gear case | |
| 71 | Eccentric shaft | |
| 72 | Circlip | |
| 73 | Striking fork | |
| 74 | Pin | |
| 75 | Spring | |
| 76 | Screw | |
| 77 |  |
Knob |
| 78 |  |
Knob spring |
| 79 |  |
Locating piece |
| 80 |  |
Screw |
| 81 |  |
Screw |
| 82 |  |
Switch knob |
| 83 |  |
Ball bearing |
| 84 |  |
Rotor |
| 85 |  |
Ball bearing |
| 87 |  |
Air guider |
| 88 |  |
Stator |
| 89 |  |
Motor housing |
| 90 |  |
Label |
| 91 |  |
Screw |
| 92 |  |
Carbon brushes |
| 93 |  |
Brush holders |
| 94 |  |
Label |
| 95 |  |
Rubber nail |
| 96 |  |
Bottom cover |
| 97 |  |
Tap screw |
| 98 |  |
Left handle |
| 99 |  |
Cord |
| 100 |  |
Cord sheath |
| 101 |  |
Cord clamp |
| 102 |  |
Tap screw |
| 103 |  |
Capacitance |
| 104 |  |
Switch |
| 105 |  |
Inductance |
| 106 |  |
Anti-vibration ring |
| 107 |  |
Tap screw |
| 108 |  |
Right handle |
| 109 |  |
Speed dial |
| 110 |  |
Collar |
| 111 |  |
Plastic cap screw |
| 112 |  |
Handle clamp |
| 113 |  |
Nut |
| 114 |  |
Depth gauge clamp |
| 115 |  |
Bolt |
| 116 |  |
Straight pin |
| 117 |  |
Auxiliary handle |
| 118 |  |
Depth gauge |
| 119 |  |
Grease pot |
| 120 |  |
Dust cap |
| 121 |  |
Spanner |
| 122 |  |
Anti-vibration bolt |
| 123 |  |
Anti-vibration washer |
| 124 |  |
Anti-vibration spring |
