BSS 610
BSS 610
| П-п | Арт | Название |
|---|---|---|
| 1 | TAPPING SCREW 4X18 | |
| 2 | HANDLE COVER COMPLETE | |
| 3 | SWITCH | |
| 4 | COMPRESSION SPRING 4 | |
| 5 | LOCK OFF LEVER | |
| 6 | POWER SUPPLY CIRCUIT | |
| 7 | COMPRESSION SPRING 4 | |
| 8 | LEAD UNIT | |
| 9 | TERMINAL | |
| 10 | SWITCH LEVER | |
| 11 | TAPPING SCREW 4X18 | |
| 12 | REAR COVER | |
| 13 | BRUSH HOLDER CAP | |
| 14 | CARBON BRUSH CB-441 | |
| 15 | PAN HEAD SCREW M5X40 | |
| 16 | BRUSH HOLDER | |
| 17 | BRUSH HOLDER | |
| 18 | BSS610 NAME PLATE | |
| 19 | MOTOR HOUSING COMPLETE | |
| 20 | YOKE UNIT | |
| 21 | BAFFLE PLATE | |
| 22 | TAPPING SCREW 4X65 | |
| 23 | BALL BEARING 627DDW | |
| 24 | ARMATURE ASS\\\'Y 18V INC. 23,25,26 | |
| 25 | FAN 55 | |
| 26 | BALL BEARING 6000LLB | |
| 27 | SHAFT LOCK | |
| 28 | COMPRESSION SPRING 5 | |
| 29 | PAN HEAD SCREW M4X12 | |
| 30 | BLOWER NOZZLE | |
| 31 | BLADE CASE SET INC. 32 | |
| 32 | MAKITA LOGO PLATE | |
| 33 | RUBBER RING 6 | |
| 34 | COUNTERSUNK SCREW M6 | |
| 35 | BALL BEARING 606ZZ | |
| 36 | RETAINING RING S-12 | |
| 37 | SPUR GEAR 52 | |
| 38 | RING 12 | |
| 39 | O RING 39 | |
| 40 | COUNTERSUNK HEAD SCREW M5X16 | |
| 41 | BEARING BOX | |
| 42 | BALL BEARING 6001DDW | |
| 43 | SPINDLE | |
| 44 | BEARING RETAINER 19-29 | |
| 45 | THICKNESS RING | |
| 46 | TENSION SPRING 3 | |
| 47 | SAFETY COVER | |
| 48 | RETAINING RING (EXT) S-34 | |
| 49 | INNER FLANGE 40 | |
| 50 | OUTER FLANGE 40 | |
| 51 | HEX. SOCKET HEAD BOLT M6X20 | |
| 52 | LED CIRCUIT | |
| 53 | CONNECTOR BOX | |
| 54 | LIGHT COVER | |
| 55 | TAPPING SCREW BIND CT 4X12 | |
| 56 | STOP RING E-8 | |
| 57 | LEVER 40 | |
| 58 | HEX.NUT M6 | |
| 59 | FLAT WASHER 6 | |
| 60 | DEPTH GUIDE | |
| 61 | HEX. LOCK NUT M5-8 | |
| 62 | ANGULAR GUIDE | |
| 63 | STOPPER | |
| 64 | O RING 9 | |
| 65 | TRUSS HEAD SCREW M5 | |
| 66 | FLAT HEAD SCREW M6X90 | |
| 67 | SHOULDER PIN 6-7 | |
| 68 | SHOULDER PIN 6-7 | |
| 69 | H.S.SET SCREW(FLAT POINT)M5X6 | |
| 70 | CAP SQUARE NECK BOLT M6X20 | |
| 71 | COMPRESSION SPRING 6 | |
| 72 | SCREW M5X20 | |
| 73 | FLAT WASHER 6 | |
| 76 | HEX. NUT M6 | |
| 77 | STOP RING E-8 | |
| 78 | LEVER 30 | |
| 79 | H.S.SET SCREW(FLAT POINT)M5X6 | |
| 80 | H.S.SET SCREW(CUP POINT)M5X8 | |
| 81 | BASE COMPLETE | |
| 82 | H.S.SET SCREW(CUP POINT)M5X8 | |
| 83 | DUST NOZZLE | |
| 84 | PAN HEAD SCREW M4X12 | |
| 85 | FLAT WASHER 7 | |
| A01 | GUIDE RULE | |
| A02 | DC18RC FAST CHARGER | |
| A03 | BATTERY BL1830 SET | |
| A04 | HEX. WRENCH 5 | |
| A05 | PLASTIC CARRYING CASE COMPLETE | |
| A06 | T.C.T.SAW BLADE 165X24TX20 | |
| A07 | BSS610RFE PLASTIC CASE LABEL | |
| A08 | BATTERY COVER | |
| E01 | CONTROLLER | |
| E02 | LINE FILTER |
