BTP 130
BTP 130
| П-п | Арт | Название |
|---|---|---|
| 1 |  |
HOUSING SET (NEW) |
| 2 |  |
BTP130 NAME PLATE |
| 3 |  |
TAPPING SCREW BIND PT 3X16 |
| 4 |  |
MODE CHANGE LEVER ASSY |
| 5 |  |
F/R CHANGE LEVER |
| 6 |  |
SWITCH TG553FSB-2 |
| 7 |  |
#ИМЯ? |
| 8 |  |
TERMINAL |
| 9 |  |
RING SPRING 11 |
| 10 |  |
FLAT WASHER 12 |
| 11 |  |
COMPRESSION SPRING 13 |
| 12 |  |
SLEEVE |
| 13 |  |
BUMPER (NEW) |
| 14 |  |
STEEL BALL 3.5 |
| 15 |  |
IMPACT ASSY (NEW) |
| 16 |  |
YOKE UNIT |
| 17 |  |
ARMATURE (NEW) |
| 18 |  |
CARBON BRUSH CB-440 |
| 19 |  |
BRUSH HOLDER COMPLETE (NEW) |
| 20 |  |
RUBBER PIN 4 |
| 21 |  |
REAR COVER |
| 22 |  |
TAPPING SCREW BIND PT 3X16 |
| 24 |  |
LIGHT CIRCUIT |
| 25 |  |
HOUSING SET (NEW) |
| 26 |  |
HOOK (NEW) |
| 27 |  |
SCREW M4X12 |
| 31 |  |
PAN HEAD SCREW M4X16 (NEW) |
| 32 |  |
HAMMER CASE |
| 33 |  |
BALL BEARING 6802LLB |
| 34 |  |
RETAINING RING R-24 |
| 35 |  |
LEAF SPRING |
| 36 |  |
CHANGE RING |
| 37 |  |
PLATE A |
| 38 |  |
CHANGE CASE |
| 39 | RETAINING RING WR-15 | |
| 40 | CAM A | |
| 41 | CAM B | |
| 42 | STEEL BALL 3.5 | |
| 43 | FLAT WASHER 15 | |
| 44 | HAMMER CHANGE LEVER | |
| 45 | PUSHER U | |
| 46 | GEAR CASE | |
| 47 | PUSHER L | |
| 48 | HEX. NUT M4 | |
| 49 | O RING 12.5 | |
| 50 | BALL BEARING 6802LLB | |
| 51 | NYLON WASHER 15 | |
| 52 | ANVIL M | |
| 53 | COMPRESSION SPRING 4 | |
| 54 | STEEL BALL 7.1 | |
| 55 | SHOULDER PIN 3-6 | |
| 56 | GUIDE | |
| 57 | RING 40 | |
| 58 |  |
HAMMER |
| 59 |  |
STEEL BALL 3.5 |
| 60 |  |
FLAT WASHER 24 |
| 61 |  |
COMPRESSION SPRING 24 (NEW) |
| 62 |  |
CUP WASHER 14 |
| 63 |  |
STEEL BALL 5.6 |
| 64 |  |
SPINDLE COMPLETE |
| 65 |  |
COMPRESSION SPRING 41 |
| 66 |  |
CLUTCH CAM |
| 67 |  |
BALL BEARING 6805LLB |
| 68 |  |
INTERNAL GEAR 50 |
| 69 |  |
CLUTCH CHANGE LEVER |
| 70 |  |
SPUR GEAR 22 |
| 71 |  |
SPUR GEAR 7-38 COMPLETE (NEW) |
| 72 |  |
SPUR GEAR 10 |
| 73 |  |
FLAT WASHER 25 |
| 76 |  |
SPEED CHANGE RING COMPLETE |
| 77 |  |
WASHER 10 |
| 78 |  |
MOTOR BLACKET |
| 79 |  |
PLATE B |
| 80 |  |
PLATE C |
| 81 |  |
FLAT WASHER 40 |
| A01 |  |
DC18RC FAST CHARGER |
| A02 |  |
BATTERY BL1430 SET |
| A03 |  |
PLASTIC CARRYING CASE (NEW) |
| A04 |  |
BTP130RFE PLASTIC CASE LABEL |
| A05 |  |
1/4\\\" HEX BIT ASSORTMENT FOR |
| A06 |  |
BATTERY COVER |
