| П-п | Арт | Название |
|---|---|---|
| 001 |  |
HANDLE SET |
| INC. 25 |  |
|
| 002 |  |
TAPPING SCREW 4X40 |
| 003 |  |
TAPPING SCREW 4X50 |
| 004 |  |
TAPPING SCREW 4X18 |
| 005 |  |
PACKING |
| 006 |  |
PLANE BEARING 4 |
| 007 |  |
LEAF SPRING |
| 008 |  |
PIN 4 |
| 009 |  |
PAN HEAD SCREW M4X10 |
| 010 |  |
PAN HEAD SCREW M4X10 |
| 011 |  |
LINEAR GUIDE |
| 012 |  |
LINEAR GUIDE |
| 013 |  |
GEAR HOUSING COVER COMPLETE |
| 014 |  |
LIGHT CIRCUIT |
| 015 |  |
HEAT SINK |
| 016 | PAN HEAD SCREW M3X8 | |
| 017 | LEAF SPRING | |
| 018 | LOCK OFF BUTTON | |
| 019 | SWITCH C3LA-2A-PLSR | |
| 020 | COMPRESSION SPRING 4 | |
| 021 | SWITCH LEVER | |
| 022 | SAFETY WIRE | |
| 023 | TAPPING SCREW CT 4X16 | |
| 024 | TERMINAL | |
| 025 | HANDLE SET | |
| INC. 1 | ||
| 026 | PIN 4 | |
| 027 | STOP RING E-3 | |
| 028 | SLIDER | |
| 029 | TORSION SPRING 6 | |
| 030 | TOOL OPENER | |
| 031 | + PAN HEAD SCREW M4 | |
| 032 | PUSH PIN | |
| 033 | DUST COVER | |
| 034 | RETAINING RING R-18 | |
| 035 | ROD | |
| 036 | TORSION SPRING 15 | |
| 037 | BLADE HOLDER | |
| 038 | MOTOR HOUSING SET | |
| INC. 63 | ||
| 039 | TAPPING SCREW 4X18 | |
| 040 | BJV140 NAME PLATE | |
| 041 | ENDBELL COMPLETE | |
| 042 | YOKE UNIT | |
| 043 | ARMATURE | |
| 044 | RETAINING RING S-8 | |
| 045 | NEEDLE BEARING 407 | |
| 046 | HEX. SOCKET HEAD BOLT M4X12 | |
| 047 | CRANK COMPLETE | |
| 048 | BALANCE PLATE | |
| 049 | GEAR COMPLETE | |
| 050 | PUSH PLATE | |
| 051 | FLAT WASHER 8 | |
| 052 | TAPPING SCREW 4X30 | |
| 053 | STOP RING E-5 | |
| 054 | SEAL PLATE | |
| 055 | CAP 5 | |
| 056 | COMPRESSION SPRING 3 | |
| 057 | LEVER 17 | |
| 058 | PIN 4 | |
| 059 | GEAR HOUSING COMPLETE | |
| 060 | SQUARE NUT M5-8 | |
| 061 | DUST SEAL | |
| 062 | RETAINER COMPLETE | |
| 063 | MOTOR HOUSING SET | |
| INC. 38 | ||
| 064 | CARBON BRUSH CB-430 | |
| 065 | BRUSH HOLDER CAP | |
| 066 | LEAF SPRING | |
| 067 | HEX. SOCKET HEAD BOLT M5X18 | |
| 068 | CRANK PLATE | |
| 069 | BASE | |
| 070 | COUNTERSUNK HEAD SCREW M4X8 | |
| 071 | BASE PLATE | |
| A01 | ANTI-SPLINTERING DEVICE | |
| A02 | COVER PLATE | |
| A03 | DUST NOZZLE | |
| A04 | JIGSAW BLADE NO.B22 | |
| A05 | JIGSAW BLADE NO.B10 | |
| A06 | JIGSAW BLADE NO.BR13 | |
| A07 | HEX. WRENCH 4 | |
| A08 | DC18RA FAST CHARGER | |
| A09 | BATTERY BL1430 SET | |
| A10 | PLASTIC CARRYING CASE | |
| A11 | BJV140RF TOOL LABEL | |
| A12 | BATTERY COVER |
