| П-п | Арт | Название |
|---|---|---|
| 1 |  |
HANDLE SET INC. 35 |
| 2 |  |
TAPPING SCREW 4X40 |
| 3 |  |
TAPPING SCREW 4X50 |
| 4 |  |
TAPPING SCREW 4X18 |
| 5 |  |
PACKING |
| 6 |  |
PLANE BEARING 4 |
| 7 |  |
LEAF SPRING |
| 8 |  |
PIN 4 |
| 9 |  |
PAN HEAD SCREW M4X10 |
| 10 |  |
PAN HEAD SCREW M4X10 |
| 11 |  |
LINEAR GUIDE |
| 12 |  |
LINEAR GUIDE |
| 13 |  |
GEAR HOUSING COVER COMPLETE |
| 14 |  |
SEAL PLATE |
| 15 |  |
TORSION SPRING 6 |
| 16 |  |
+ PAN HEAD SCREW M4 |
| 17 |  |
TOOL OPENER |
| 18 |  |
DUST COVER |
| 19 |  |
RETAINING RING R-18 |
| 20 |  |
ROD ASS\\\\\'Y INC. 18,19,21-23 |
| 21 |  |
TORSION SPRING 15 |
| 22 |  |
BLADE HOLDER |
| 23 |  |
PUSH PIN |
| 24 |  |
POWER SUPPLY CORD 1.0-2-2.5 |
| 25 |  |
CORD GUARD 8 |
| 26 |  |
STRAIN RELIEF |
| 27 |  |
TAPPING SCREW 4X18 |
| 28 |  |
NOISE SUPPRESSOR |
| 29 |  |
TAPPING SCREW CT 4X16 |
| 30 |  |
SAFETY WIRE |
| 31 |  |
LED CIRCUIT |
| 32 |  |
CONTROLLER |
| 33 |  |
SWITCH TGL115CDT-1 |
| 34 |  |
TERMINAL BLOCK 1P |
| 35 |  |
HANDLE SET INC. 1 |
| 36 |  |
SLIDER |
| 37 |  |
STOP RING E-3 |
| 38 |  |
RETAINING RING S-8 |
| 39 |  |
NEEDLE BEARING 407 |
| 40 |  |
PIN 4 |
| 41 |  |
HEX. SOCKET HEAD BOLT M4X12 |
| 42 |  |
CRANK COMPLETE |
| 43 |  |
BALANCE PLATE |
| 44 |  |
GEAR COMPLETE |
| 45 |  |
PUSH PLATE |
| 46 |  |
FLAT WASHER 8 |
| 47 |  |
TAPPING SCREW 4X30 |
| 48 |  |
STOP RING E-5 |
| 49 |  |
CAP 5 |
| 50 |  |
COMPRESSION SPRING 3 |
| 51 |  |
LEVER 17 |
| 52 |  |
PIN 4 |
| 53 |  |
RETAINER COMPLETE |
| 54 |  |
SQUARE NUT M5-8 |
| 55 |  |
DUST SEAL |
| 56 |  |
GEAR HOUSING COMPLETE |
| 57 |  |
BALL BEARING 608DDW |
| 58 |  |
FAN 52 |
| 59 |  |
TAPPING SCREW 4X60 |
| 60 |  |
BAFFLE PLATE |
| 61 |  |
FIELD ASS\\\\\'Y 220-240V |
| 62 |  |
ARMATURE ASS\\\\\'Y 220-240V INC. 57,58,73,74 |
| 63 | CARBON BRUSH CB-419 | |
| 64 | BRUSH HOLDER | |
| 66 | 4350FCT NAME PLATE | |
| 68 | MOTOR HOUSING | |
| 69 | SELF LOCK 6 | |
| 70 | MAGNET SLEEVE | |
| 71 | WAVE WASHER 6 | |
| 72 | RUBBER RING 19 | |
| 73 | BALL BEARING 607LLB | |
| 74 | INSULATION WASHER | |
| 75 | LEAF SPRING | |
| 76 | HEX. SOCKET HEAD BOLT M5X18 | |
| 77 | CRANK PLATE | |
| 78 | BASE | |
| 79 | COUNTERSUNK HEAD SCREW M4X8 | |
| 80 | BASE PLATE | |
| A01 | ANTI-SPLINTERING DEVICE | |
| A02 | COVER PLATE | |
| A03 | JIGSAW BLADE NO.B22 | |
| A04 | JIGSAW BLADE NO.B10 | |
| A05 | JIGSAW BLADE NO.BR13 | |
| A06 | HEX. WRENCH 4 | |
| A07 | PLASTIC CARRYING CASE | |
| A08 | DUST NOZZLE |
