| П-п | Арт | Название |
|---|---|---|
| 1 | O-RING 65 | |
| 2 | PAN HEAD SCREW M5X20 | |
| 3 | FLANGE 90 | |
| 4 | TOOLLESSBOLT ASSEMBLY | |
| 5 | PLUG | |
| 6 | PLUG | |
| 7 | SAFETY GUIDE | |
| 8 | FLAT HEAD SCREW M6 | |
| 9 | THUMB SCREW M6X12 | |
| 10 | FLAT HEAD SCREW M6 | |
| 11 | CENTER COVER | |
| 011-1 | CENTER COVER | |
| 13 | O RING 14 | |
| 14 | RING 17 | |
| 15 | FLANGE 90 | |
| 16 | RING 17 | |
| 17 | SAFETY COVER | |
| 18 | BALL BEARING 6203ZZ | |
| 19 | BEARING BOX | |
| 20 | HELICAL GEAR 50 | |
| 21 | SPINDLE | |
| 22 | BALL BEARING 6000ZZ | |
| 23 | HANDLE SET | |
| D10 | INC. 30 | |
| 24 | SWITCH TGC31B | |
| 25 | SWITCH LEVER | |
| 26 | SWITCH LOCK | |
| 27 | COMPRESSION SPRING 4 | |
| 30 | HANDLE SET | |
| D10 | INC. 23 | |
| 31 | SWITCH BUTTON | |
| 031-1 | SWITCH BUTTON | |
| 32 | TAPPING SCREW 4X18 | |
| 34 | PAN HEAD SCREW M5X40 | |
| 36 | NOISE SUPPRESSOR | |
| 37 | LINE FILTER | |
| 38 | TAPPING SCREW 4X18 | |
| 39 | STRAIN RELIEF | |
| 40 | POWER SUPPLY CORD 1.0-2-3.0 | |
| 41 | CORD GUARD 9.3-90 | |
| 42 | LW1400 NAME PLATE | |
| 43 | MOTOR HOUSING COMPLETE | |
| C10 | BRUSH HOLDER | |
| 44 | BRUSH HOLDER CAP 7-18 | |
| 45 | CARBON BRUSH CB-203 | |
| 46 | PAN HEAD SCREW M5X40 | |
| 47 | FIELD ASST 220V | |
| C10 | RING TERMINAL | |
| C20 | CONNECTOR P-2 | |
| 48 | TAPPING SCREW 5X85 | |
| 49 | BAFFLE PLATE | |
| 50 | BALL BEARING 6200ZZ | |
| 51 | ARMATURE ASST 220-240V | |
| D10 | INC. 50,52-54,97 | |
| 52 | FAN 80 | |
| 53 | WASHER 15 | |
| 54 | BALL BEARING 6200ZZ | |
| 55 | STOPPER | |
| 56 | COMPRESSION SPRING 7 | |
| 57 | GEAR HOUSING COMPLETE | |
| C10 | RUBBER PIN 6 | |
| 057-1 | GEAR HOUSING COMPLETE S | |
| C10 | RUBBER PIN 6 | |
| 58 | SPRING PIN 5-20 | |
| 59 | HANDLE 120 | |
| 60 | VISE SCREW | |
| 63 | H.S.SET SC RE W( FLAT POINT)M6X16 | |
| 65 | VISE NUT | |
| 66 | PLATE | |
| 67 | SCREW GUIDE | |
| 68 | SPRING PIN 5-36 | |
| 69 | SPRING PIN 4-16 | |
| 70 | PAN HEAD SCREW M8X30 | |
| 71 | COLLAR BOLT M10X20 | |
| 72 | KNOB 40 | |
| 73 | GUIDE PLATE | |
| 74 | HEX. NUTM10 | |
| 074-1 | HEX.NUT M10-17 | |
| 75 | SPRING WASHER 10 | |
| 76 | FLAT WASHER 10 | |
| 77 | PIPE 20-128 | |
| 78 | TORSION SPRING 33 | |
| 81 | SPARK GUARD | |
| 82 | PAN HEAD SCREW M6X12 | |
| 83 | CUSHION | |
| 84 | FLAT WASHER 10 | |
| 85 | HEX.BOLT M10X140 | |
| 86 | BASE | |
| 87 | RETAINING RING S-8 | |
| 88 | FLAT WASHER 8 | |
| 89 | PIN 16 | |
| 90 | RETAINING RING S-16 | |
| 91 | FLAT WASHER 8 | |
| 92 | VISE PLATE | |
| 93 | WAVE WASHER 6 | |
| 94 | FLAT WASHER 6 | |
| 97 | INSULATION WASHER | |
| 98 | PAN HEAD SCREW M4X6 | |
| 99 | SPARK COVER | |
| 100 | H.S.SET SC RE W( FLAT POINT)M5X6 | |
| 101 | LEVER 125 | |
| 102 | FLAT WASHER 10 | |
| 103 | SLEEVE 11 | |
| 104 | FLAT WASHER 10 | |
| 105 | THRUST NEEDLE CAGE 1024 | |
| 106 | THIN WASHER 10 | |
| 107 | THIN WASHER 10 | |
| 108 | THRUST NEEDLE CAGE 1024 | |
| 109 | THIN WASHER 10 | |
| 110 |  |
STOP RING E-8 |
| 111 |  |
GUIDE BASE |
| 112 |  |
SLEEVE 20 |
| 113 |  |
STOP RING E-8 |
| 114 |  |
0 RING 7 |
| 115 |  |
STOPPER PIN |
| 116 |  |
HEX. SOCKET HEAD BOLT M6X12 |
| 116-1 |  |
HEX. SOCKET HEAD BOLT M6X12 S |
| 117 |  |
SPRING WASHER 6 |
| 118 |  |
HEX. NUT M6 |
| 119 |  |
VISE ASST |
| D10 |  |
INC. 58-60,65-69,87-92 |
| A01 |  |
14\\\" CUT-OFF WHEEL |
