| П-п | Арт | Название |
|---|---|---|
| 1 |  |
HEX. BOLT M10X25 |
| 2 |  |
INNER FLANGE 100 |
| 3 |  |
RING 20 |
| 4 |  |
INNER FLANGE 100 |
| 5 |  |
HEX. BOLT M5X14 |
| 6 |  |
PRESSURE PLATE |
| 7 |  |
PLATE B |
| 8 |  |
CAP 32 |
| 9 |  |
CAP SQUARE NECK BOLT M8X30 |
| 10 |  |
WHEEL COVER ASS\\\'Y |
| 11 |  |
COUNTERSUNK HEAD SCREW M5X8 |
| 12 |  |
LOCK PLATE |
| 13 |  |
THUMB NUT M8 |
| 14 |  |
GRIP |
| 15 |  |
HEX. BOLT M8X20 |
| 16 |  |
HEX. BOLT M8X20 |
| 17 |  |
SPINDLE COMPLETE |
| 18 |  |
HEX. BOLT M5X20 |
| 19 |  |
BEARING BOX COMPLETE |
| 20 |  |
FLAT WASHER 20 |
| 21 |  |
BALL BERING 6004DDW |
| 22 |  |
BEARING RETAINER 50 |
| 23 |  |
PAN HEAD SCREW M5X16 |
| 24 |  |
O RING 80 |
| 25 |  |
LOCK SLEEVE |
| 26 |  |
LOCK SPRING 24 |
| 27 |  |
SPIRAL BEVEL GEAR 48 |
| 28 | FLAT WASHER 15 | |
| 29 | RETAINING RING S-15 | |
| 30 | BALL BEARING 6000LLB | |
| 31 | HEX. BOLT M5X40 | |
| 32 | GEAR HOUSING COMPLETE | |
| 33 | HEX. NUT M8-12 | |
| 34 | SPIRAL BEVEL GEAR 9 | |
| 35 | RUBBER RING 36 | |
| 36 | BALL BEARING 6202DDW | |
| 37 | FLAT WASHER 30 | |
| 38 | RETAINING RING R-40 | |
| 39 | FLAT WASHER 15 | |
| 40 | FAN 80 | |
| 41 | ARMATURE ASS\\\'Y 220-240V INC. 40,42,43 | |
| 42 | INSULATION WASHER | |
| 43 | BALL BEARING 6200DDW | |
| 44 | TAPPING SCREW 5X75 | |
| 45 | BAFFLE PLATE | |
| 46 | FIELD 220-240V | |
| 47 | MOTOR HOUSING INC. 48 | |
| 48 | MAKITA MARK | |
| 49 | BRUSH HOLDER CAP | |
| 50 | A.C. CARBON BRUSH CB-204 | |
| 51 | NAME PLATE 4112HS | |
| 52 | DUST COVER | |
| 55 | SWITCH 1362.0113 | |
| 56 | HANDLE SET INC. 62 | |
| 57 | TAPPING SCREW 4X20 | |
| 58 | TAPPING SCREW 4X18 | |
| 59 | STRAIN RELIEF | |
| 60 | CORD GUARD 10 | |
| 61 | POWER SUPPLY CORD 1.5-2-2.5 | |
| 62 | HANDLE SET INC. 56 | |
| 63 | NOISE SUPPRESSOR | |
| 64 | SOFT START CIRCUIT | |
| 65 | WING BOLT M8X20 | |
| 66 | SPRING WASHER 8 | |
| 67 | FLAT WASHER 8 | |
| 68 | BASE | |
| 69 | LINE FILTER | |
| 70 | SHOULDER HEX. BOLT M6 | |
| 71 | SHOULDER HEX. BOLT M6 | |
| A01 | SOCKET WRENCH 17 | |
| A02 | PLASTIC CARRYING CASE |
