| П-п | Арт | Название |
|---|---|---|
| 1 |  |
BLADE CLAMP |
| 2 |  |
HEX. SOCKET HEAD BOLT M5X15 |
| 3 |  |
H.SOCKET SET SCREW(HOLE)M8X10 |
| 4 |  |
TAPPING SCREW BIND CT 5X12 |
| 5 |  |
FELT RETAINER |
| 6 |  |
FELT RING 14 |
| 7 |  |
FLAT WASHER 14 |
| 8 |  |
X RING 14 |
| 9 |  |
FLAT WASHER 16 |
| 10 |  |
GEAR HOUSING COVER |
| 11 |  |
PAN HEAD SCREW M5X30 |
| 12 |  |
SHOE |
| 19 |  |
INSULATION COVER |
| 20 |  |
SLEEVE 9 |
| 21 |  |
INNER PLATE |
| 22 |  |
PAN HEAD SCREW M4X10 |
| 23 |  |
LOCK PLATE |
| 24 |  |
HEX. BOLT M8X25 |
| 25 |  |
LEVER 60 |
| 26 |  |
HEX. NUT M4 |
| 27 |  |
PACKING |
| 28 |  |
PLATE 12X16 |
| 29 |  |
PLANE BEARING 14 |
| 30 |  |
PLATE |
| 31 |  |
PAN HEAD SCREW M5X16 |
| 32 |  |
SLIDE PLATE |
| 33 |  |
SLIDER |
| 34 |  |
NEEDLE BEARING 708 |
| 35 | HEX. SOCKET HEAD BOLT M10X18 | |
| 36 | GEAR COMPLETE | |
| 37 | PLATE 12X16 | |
| 38 | PLANE BEARING 14 | |
| 39 | PLATE | |
| 40 | PAN HEAD SCREW M5X16 | |
| 41 | BEARING RETAINER 56 | |
| 42 | BALL BEARING 6202LLB | |
| 43 | RING 15 | |
| 44 | BALL BEARING 6902 | |
| 45 | HEX. SOCKET HEAD BOLT M5X12 | |
| 46 | PLATE (C) | |
| 47 | TAPPING SCREW 5X30 | |
| 48 | GEAR HOUSIHG | |
| 49 | BEARING RETAINER | |
| 50 | PAN HEAD SCREW M5X8 | |
| 51 | TAPPING SCREW 5X45 | |
| 52 | GEAR SHAFT | |
| 53 | PAN HEAD SCREW M5X8 | |
| 54 | RETAINING RING S-12 | |
| 55 | BALL BEARING 6001DDW | |
| 56 | ARMATURE ASS\\\'Y 220V INC. 61,62 | |
| 57 | BAFFLE PLATE | |
| 58 | TAPPING SCREW 5X60 | |
| 59 | RETAINER | |
| 60 | FIELD ASS\\\'Y 220V | |
| 61 | INSULATION WASHER | |
| 62 | BALL BEARING 608DDW | |
| 63 | NAME PLATE JR3030 | |
| 64 | MOTOR HOUSING COMPLETE | |
| 65 | CARBON BRUSH CB-303 | |
| 66 | BRUSH HOLDER CAP 7-11 | |
| 67 | TAPPING SCREW 4X20 | |
| 68 | HANDLE SET INC. 70 | |
| 69 | SWITCH LEVER | |
| 70 | HANDLE SET INC. 68 | |
| 71 | COMPRESSION SPRING 4 | |
| 72 | LOCK-ON BUTTON | |
| 73 | SWITCH SGE106CV-1P | |
| 74 | TAPPING SCREW 4X18 | |
| 75 | STRAIN RELIEF | |
| 76 | CORD GUARD 9.3-90 | |
| 77 | POWER SUPPLY CORD 1.0-2-4.0 | |
| 78 | COMPRESSION SPRING 5 | |
| A01 | RECIPRO SAW BLADE NO.21 | |
| A02 | RECIPRO SAW BLADE NO.22 | |
| A03 | RECIPRO SAW BLADE NO.23 | |
| A04 | WRENCH HOLDER 3.4 | |
| A05 | HEX. WRENCH 4 | |
| A07 | PLASTIC CARRYING CASE | |
| E02 | NOISE SUPPRESSOR | |
| E03 | EARTH TERMINAL |
