| П-п | Арт | Название |
|---|---|---|
| 1 | PAN HEAD SCREW M5X18 | |
| 2 | FLAT WASHER 5 | |
| 3 | SAFETY COVER (NEW) | |
| 4 | FLAT HEAD SCREW M5 | |
| 5 | HEX. S.F.H. BOLT M6X16 (NEW) | |
| 6 | INNER FLANGE 40 (NEW) | |
| 7 | BEARING RETAINER 55 | |
| 8 | SPINDLE | |
| 9 | BALL BEARING 6201DDW | |
| 10 | BEARING BOX | |
| 11 | O RING 42 | |
| 12 | RING 12 | |
| 13 | HELICAL GEAR 47 | |
| 14 | BALL BEARING 607LLB | |
| 15 | RUBBER PIN 6 | |
| 16 | BLADE CASE COMPL. (NEW) | |
| 17 |  |
SPIRAL SPRING 26 |
| 18 |  |
CENTER WASHER (NEW) |
| 19 |  |
HEX. HEAD BOLT M6X16 (NEW) |
| 20 |  |
CENTER COVER |
| 21 |  |
CENTER PLATE (NEW) |
| 22 |  |
OUTER FLANGE 40 (NEW) |
| 23 |  |
PAN HEAD SCREW M5X16 |
| 24 |  |
HEX. SOCKET HEAD BOLT M6X20 |
| 25 |  |
FLAT WASHER 6 |
| 26 |  |
RING 6 |
| 27 |  |
LINK PLATE COMPLETE (NEW) |
| 28 |  |
RING 6 |
| 29 |  |
FLAT WASHER 6 |
| 30 |  |
STOP RING E-5 |
| 31 |  |
TAPPING SCREW BIND CT 4X8 |
| 32 |  |
O RING 35 |
| 33 |  |
DUST NOZZLE (NEW) |
| 34 |  |
MAKITA LOGO LABLE (NEW) |
| 35 |  |
HEX. SOCKET HEAD BOLT M6X16 (NEW) |
| 36 |  |
URETHANE RING 5 |
| 37 |  |
SCREW M6X43 |
| 38 |  |
GUARD PLATE COMPLETE (NEW) |
| 39 |  |
PAN HEAD SCREW M4X10 |
| 40 |  |
GUARD (NEW) |
| 62 |  |
LOCK PIN |
| 63 |  |
ROD HOLDER |
| 64 |  |
TAPPING SCREW CT 4X16 |
| 65 |  |
COMPRESSION SPRING 7 |
| 66 |  |
ROD 8 |
| 67 |  |
CAP |
| 68 |  |
LOCK LEVER (NEW) |
| 69 |  |
PAN HEAD SCREW M4X10 |
| 70 |  |
LOCK PLATE |
| 71 |  |
PAN HEAD SCREW M4X10 |
| 72 |  |
TAPPING SCREW 5X50 |
| 73 |  |
RUBBER PIN 4 |
| 74 |  |
BALL BEARING 6001LLB |
| 75 |  |
RUBBER PIN 4 |
| 76 |  |
COMPRESSION SPRING 5 |
| 77 | SHAFT LOCK | |
| 78 | FAN 70 | |
| 79 | ARMATURE ASS\\\'Y 220V INC. 74,78,80,81 | |
| 80 | INSULATION WASHER | |
| 81 | BALL BEARING 608LLB | |
| 82 | URETHANE WASHER 18 | |
| 83 | BAFFLE PLATE | |
| 84 | FIELD 220V (NEW) | |
| 85 | SUPPORT COMPLETE | |
| 86 | HANDLE SET (NEW) | |
| 87 | POWER SUPPLY CORD 1.0-2-3.3 | |
| 88 | CORD GUARD 9.3-90 | |
| 89 | STRAIN RELIEF (NEW) | |
| 90 | TAPPING SCREW 4X18 | |
| 91 | MOTOR HOUSING COMPLETE INC. 73 | |
| 92 | UPPER COVER | |
| 93 | PAN HEAD SCREW M5X50 | |
| 94 | CARBON BRUSH CB-303 | |
| 95 | BRUSH HOLDER CAP 7-11 | |
| 96 | NAME PLATE LS0714F (NEW) | |
| 97 | SWITCH TG71B | |
| 98 | NOISE SUPPRESSOR | |
| 99 | SWITCH LEVER | |
| 101 | TERMINAL BLOCK 1P | |
| 102 | PIN 5 | |
| 103 | LOCK OFF LEVER | |
| 104 | COMPRESSION SPRING 4 | |
| 105 | PAN HEAD SCREW M5X50 | |
| 107 | SWITCH BUTTON | |
| 109 | HANDLE SET (NEW) | |
| 110 | TAPPING SCREW 4X18 | |
| 111 | LEAD UNIT | |
| 112 | LIGHT ASS\\\'Y | |
| 113 | TAPPING SCREW 4X18 | |
| 114 | GUIDE FENCE (NEW) | |
| 115 | HSH BOLT M6X25 WITH WG (NEW) | |
| 116 | SCREW M6X10 | |
| 117 | SLEEVE 17 | |
| 118 | TORSION SPRING 28 | |
| 119 | SLEEVE 17 | |
| 120 | SCREW M6X33 | |
| 121 | COMPRESSION SPRING 6 | |
| 122 | RING 26 | |
| 123 | PIPE HOLDER | |
| 124 | H.S.SET SCREW (CUP POINT) M6X8 | |
| 125 | STRAIN RELIEF | |
| 126 | TAPPING SCREW BIND CT 4X12 | |
| 127 | STRAIN RELIEF (NEW) | |
| 128 | TAPPING SCREW BIND CT 4X12 | |
| 129 | PAN HEAD SCREW M4X10 | |
| 130 | LEVER 100 | |
| 131 | SET SCREW M4X8 | |
| 132 | HEX. NUT M10-17 | |
| 133 | COMPRESSION SPRING 5 | |
| 134 | FLAT WASHER 10 | |
| 135 | CAP 16 | |
| 136 | ARM COMPLETE | |
| 137 | RELEASE PIN | |
| 138 | HEX. BOLT M6X16 (NEW) | |
| 139 | STOPPER PLATE | |
| 140 | FLAT WASHER 6 | |
| 141 | TORSION SPRING 8 | |
| 142 | PAN HEAD SCREW M5 | |
| 143 | POINTER | |
| 144 |  |
TAPPING SCREW BIND CT 4X12 |
| 145 |  |
FRONT ARM COMPLETE |
| 146 |  |
STOPPER ARM |
| 147 |  |
WAVE WASHER 8 |
| 148 |  |
FLAT WASHER 8 |
| 149 |  |
PAN HEAD SCREW M6 |
| 150 |  |
H.S.SET SCREW(FLAT POINT)M6X10 |
| 151 |  |
H.S.SET SCREW(FLAT POINT)M6X10 |
| 152 |  |
KNOB 20 |
| 153 |  |
O RING 5 |
| 154 |  |
STOPPER PIN |
| 155 |  |
PIN 16-90 |
| 156 |  |
ARM HOLDER COMPLETE |
| 157 |  |
PIN 5 |
| 158 |  |
SCREW M10 |
| 159 |  |
FLAT WASHER 10 |
| 160 |  |
THRUST NEEDLE CAGE 1024 |
| 161 |  |
FLAT WASHER 10 |
| 162 |  |
HEX. LOCK NUT M10-17 |
| 163 |  |
RING 26 |
| 164 |  |
SCREW M6X33 |
| 165 |  |
HEX. LOCK NUT M8-13 |
| 166 |  |
FLAT WASHER 8 |
| 167 |  |
INDICATION PLATE |
| 168 |  |
TAPPING SCREW BIND CT 4X12 |
| 169 |  |
TAPPING SCREW BIND CT 4X12 |
| 170 |  |
TAPPING SCREW BIND CT 4X12 |
| 171 |  |
KERF BOARD |
| 172 |  |
KERF BOARD |
| 173 |  |
TURN BASE COMPL. (NEW) |
| 174 |  |
HEX. SOCKET HEAD BOLT M4X10 |
| 175 |  |
SQUARE ROD COMPLETE |
| 176 |  |
HEX.BOLT M5X30 |
| 177 |  |
TAPPING SCREW CT 4X16 |
| 178 |  |
LOCK PLATE |
| 179 |  |
PIN HOLDER |
| 180 |  |
PIN 3 |
| 181 |  |
LOCK PIN |
| 182 |  |
COMPRESSION SPRING 6 |
| 183 |  |
ROD 6 |
| 184 |  |
LOCK LEVER |
| 185 |  |
LOCK LEVER PLATE |
| 186 |  |
TAPPING SCREW CT 4X16 |
| 187 |  |
COMPRESSION SPRING 9 |
| 188 |  |
FLAT WASHER 8 |
| 189 |  |
ADJUST BOLT M8X27 |
| 190 |  |
GRIP 32 |
| 191 |  |
CAP 20 |
| 192 |  |
HEX. BOLT M8X50 |
| 193 | SCREW M6X10 | |
| 194 | BASE COMPLETE | |
| 195 | SLIDE PLATE | |
| 196 | SLIDE PLATE | |
| 197 | TORSION SPRING 8 | |
| 198 | PAN HEAD SCREW M4X10 | |
| 199 | GUARD (NEW) | |
| A01 | DUST BAG ASSY (NEW) | |
| A02 | VICE ASS\\\'Y | |
| A03 | SWITCH BUTTON | |
| A04 | TRIANGULAR RULE | |
| A05 | HOLDER | |
| A06 | TCT SAW BLADE 190X20X24T (NEW) | |
| A07 | HEX. WRENCH 5 (NEW) | |
| E03 | SUB LEVER | |
| E04 |  |
PAN HEAD SCREW M4X10 |
| E05 |  |
GUARD ASSY (NEW) |
| E07 |  |
SUB FENCE COMPLETE |
| E08 |  |
HEX. LOCK NUT M6-10 |
| E09 |  |
TAPPING SCREW BIND CT 4X8 |
| E10 |  |
SUB FENCE PLATE |
| E11 |  |
COUNTERSUNK HEAD SCREW M6X35 |
| E12 |  |
FLAT WASHER 6 |
