| П-п | Арт | Название |
|---|---|---|
| 1 |  |
PAN HEAD SCREW M5X18 |
| 2 |  |
FLAT WASHER 5 |
| 3 |  |
SAFETY COVER |
| 4 |  |
+ FLAT HEAD SCREW M5 |
| 5 |  |
HEX.BOLT M6X18 |
| 6 |  |
INNER FLANGE 40 |
| 7 |  |
BEARING RETAINER 55 |
| 8 |  |
SPINDLE |
| 9 |  |
BALL BEARING 6201DDW |
| 10 |  |
BEARING BOX |
| 11 |  |
O RING 42 |
| 12 |  |
RING 12 |
| 13 |  |
HELICAL GEAR 47 |
| 14 |  |
BALL BEARING 607LLB |
| 15 |  |
RUBBER PIN 6 |
| 16 |  |
BLADE CASE INC. 15,34,75 |
| 17 |  |
SPIRAL SPRING 26 |
| 18 |  |
CENTER WASHER |
| 19 |  |
HEX.BOLT M6X14 |
| 20 |  |
CENTER COVER |
| 21 |  |
CENTER PLATE |
| 22 |  |
OUTER FLANGE 40 |
| 23 |  |
PAN HEAD SCREW M5X16 |
| 24 |  |
HEX. SOCKET HEAD BOLT M6X20 |
| 25 |  |
FLAT WASHER 6 |
| 26 |  |
RING 6 |
| 27 |  |
LINK PLATE COMPLETE |
| 28 |  |
RING 6 |
| 29 |  |
FLAT WASHER 6 |
| 30 |  |
STOP RING E-5 |
| 31 |  |
TAPPING SCREWҐBINDҐCTҐ4X8 |
| 32 |  |
O RING 35 |
| 33 |  |
DUST NOZZLE |
| 34 |  |
MAKITA LOGO LABEL |
| 35 |  |
HEX. BOLT M6X16 |
| 36 |  |
URETHANE RING 5 |
| 37 |  |
SCREW M6X43 |
| 38 |  |
GUARD PLATE COMPLETE |
| 39 |  |
PAN HEAD SCREW M4X10 |
| 40 |  |
GUARD |
| 41 |  |
TAPPING SCREW BIND CT 4X12 |
| 42 |  |
LEAD COVER A |
| 43 |  |
LEAD COVER HOLDER |
| 44 |  |
LEAD COVER B |
| 45 |  |
LENS |
| 46 |  |
LASER LABEL |
| 47 |  |
SHOULDER SCREW M5 |
| 48 |  |
H.S.SET SCREW(CUP POINT)M5X8 |
| 49 |  |
BLOCK C |
| 50 |  |
H.S.SET SCREW(FLAT POINT)M4X6 |
| 51 |  |
TORSION SPRING 9 |
| 52 |  |
PAN HEAD SCREW M3X6 |
| 53 |  |
BLOCK B |
| 54 |  |
PAN HEAD SCREW M3X6 |
| 55 |  |
TORSION SPRING 9 |
| 56 |  |
H.S.SET SCREW(FLAT POINT)M4X6 |
| 57 |  |
LASER CIRCUIT COMPLETE |
| 58 |  |
TOP COVER |
| 59 |  |
FLAT WASHER 5 |
| 60 |  |
THUMB SCREW M5X24 |
| 61 |  |
TAPPING SCREW BIND CT 4X20 |
| 62 |  |
LOCK PIN |
| 63 |  |
ROD HOLDER |
| 64 |  |
TAPPING SCREW CT 4X16 |
| 65 |  |
COMPRESSION SPRING 7 |
| 66 |  |
ROD 8 |
| 67 |  |
CAP |
| 68 |  |
LOCK LEVER |
| 69 |  |
PAN HEAD SCREW M4X10 |
| 70 |  |
LOCK PLATE |
| 71 |  |
PAN HEAD SCREW M4X10 |
| 72 |  |
TAPPING SCREW 5X50 |
| 73 |  |
RUBBER PIN 4 |
| 74 |  |
BALL BEARING 6001LLB |
| 75 |  |
RUBBER PIN 4 |
| 76 |  |
COMPRESSION SPRING 5 |
| 77 |  |
SHAFT LOCK |
| 78 |  |
FAN 70 |
| 79 |  |
ARMATURE ASS\\\\\'Y 220V INC. 74,78,80,81 |
| 80 |  |
INSULATION WASHER |
| 81 |  |
BALL BEARING 608LLB |
| 82 |  |
URETHANE WASHER 18 |
| 83 |  |
BAFFLE PLATE |
| 84 |  |
FIELD 220V |
| 85 |  |
SUPPORT COMPLETE |
| 86 |  |
HANDLE SET INC. 109 |
| 87 |  |
POWER SUPPLY CORD 1.0-2-3.3 |
| 88 |  |
CORD GUARD 9.3-90 |
| 89 |  |
STRAIN RELIEF |
| 90 |  |
TAPPING SCREW 4X18 |
| 91 |  |
MOTOR HOUSING COMPLETE INC. 73 |
| 92 |  |
UPPER COVER |
| 93 |  |
PAN HEAD SCREW M5X50 |
| 94 |  |
CARBON BRUSH CB-303 |
| 95 |  |
BRUSH HOLDER CAP |
| 96 |  |
NAME PLATE LS0714FL |
| 97 |  |
SWITCH TG71B |
| 98 |  |
NOISE SUPPRESSOR |
| 99 |  |
SWITCH LEVER |
| 100 |  |
POWER SUPPLY CIRCUIT |
| 101 |  |
TERMINAL BLOCK 1P |
| 102 |  |
PIN 5 |
| 103 |  |
LOCK OFF LEVER |
| 104 |  |
COMPRESSION SPRING 4 |
| 105 |  |
PAN HEAD SCREW M5X50 |
| 106 |  |
SWITCH SLE6A |
| 107 |  |
SWITCH BUTTON |
| 108 |  |
SWITCH BOX COMPLETE |
| 109 |  |
HANDLE SET INC. 86 |
| 110 |  |
TAPPING SCREW 4X18 |
| 111 |  |
LEAD UNIT |
| 112 |  |
LIGHT ASS\\\\\'Y |
| 113 |  |
TAPPING SCREW 4X40 |
| 114 |  |
GUIDE FENCE |
| 115 |  |
HEX. BOLT M6X25 |
| 116 |  |
SCREW M6X10 |
| 117 |  |
SLEEVE 17 |
| 118 |  |
TORSION SPRING 28 |
| 119 |  |
SLEEVE 17 |
| 120 |  |
SCREW M6X33 |
| 121 |  |
COMPRESSION SPRING 6 |
| 122 |  |
RING 26 |
| 123 |  |
PIPE HOLDER |
| 124 |  |
H.S.SET SCREW(CUP POINT)M6X8 |
| 125 |  |
STRAIN RELIEF |
| 126 |  |
TAPPING SCREW BIND CT 4X12 |
| 127 |  |
WRENCH HOLDER |
| 128 |  |
TAPPING SCREW BIND CT 4X12 |
| 129 |  |
PAN HEAD SCREW M4X10 |
| 130 |  |
LEVER 100 |
| 131 |  |
SET SCREW M4X8 |
| 132 |  |
HEX. NUT M10-17 |
| 133 |  |
COMPRESSION SPRING 5 |
| 134 |  |
FLAT WASHER 10 |
| 135 |  |
CAP 16 |
| 136 |  |
ARM COMPLETE |
| 137 |  |
RELEASE PIN |
| 138 |  |
HEX. BOLT M6X16 |
| 139 |  |
STOPPER PLATE |
| 140 |  |
FLAT WASHER 6 |
| 141 |  |
TORSION SPRING 8 |
| 142 |  |
+PAN HEAD SCREW M5 |
| 143 |  |
POINTER |
| 144 |  |
TAPPING SCREW BIND CT 4X12 |
| 145 | FRONT ARM COMPLETE | |
| 146 | STOPPER ARM | |
| 147 | WAVE WASHER 8 | |
| 148 | FLAT WASHER 8 | |
| 149 | + PAN HEAD SCREW M6 | |
| 150 | H.S.SET SCREW(FLAT POINT)M6X10 | |
| 151 | H.S.SET SCREW(FLAT POINT)M6X16 | |
| 152 | KNOB 20 | |
| 153 | O RING 5 | |
| 154 | STOPPER PIN | |
| 155 | PIPE 16-90 | |
| 156 | ARM HOLDER COMPLETE | |
| 157 | PIN 5 | |
| 158 | SCREW M10 | |
| 159 | FLAT WASHER 10 | |
| 160 | THRUST NEEDLE CAGE 1024 | |
| 161 | FLAT WASHER 10 | |
| 162 | HEX. LOCK NUT M10-17 | |
| 163 | RING 26 | |
| 164 | SCREW M6X33 | |
| 165 | HEX. LOCK NUT M8-13 | |
| 166 | FLAT WASHER 8 | |
| 167 | INDICATION PLATE | |
| 168 | TAPPING SCREW BIND CT 4X12 | |
| 169 | TAPPING SCREW BIND CT 4X12 | |
| 170 | TAPPING SCREW BIND CT 4X12 | |
| 171 | KERF BOARD | |
| 172 | KERF BOARD | |
| 173 | TURN BASE COMPLETE | |
| 174 | HEX. SOCKET HEAD BOLT M4X10 | |
| 175 | SQUARE ROD COMPLETE | |
| 176 | HEX.BOLT M5X30 | |
| 177 | TAPPING SCREW CT 4X16 | |
| 178 | LOCK PLATE | |
| 179 | PIN HOLDER | |
| 180 | PIN 3 | |
| 181 | LOCK PIN | |
| 182 | COMPRESSION SPRING 6 | |
| 183 | ROD 6 | |
| 184 | LOCK LEVER | |
| 185 | LOCK LEVER PLATE | |
| 186 | TAPPING SCREW CT 4X16 | |
| 187 | COMPRESSION SPRING 9 | |
| 188 | FLAT WASHER 8 | |
| 189 | ADJUST BOLT M8X27 | |
| 190 | GRIP 32 | |
| 191 | CAP 20 | |
| 192 | HEX. BOLT M8X50 | |
| 193 | SCREW M6X10 | |
| 194 | BASE COMPLETE | |
| 195 | SLIDE PLATE | |
| 196 | SLIDE PLATE | |
| 197 | TORSION SPRING 8 | |
| 198 | PAN HEAD SCREW M4X10 | |
| 199 | GUARD | |
| 200 | STRAIN RELIEF | |
| 201 | TAPPING SCREW BIND CT 4X12 | |
| 202 | HEX. NUT M6 | |
| 203 | STAY | |
| A01 | DUST BAG ASS\\\\\'Y | |
| A02 | VICE ASS\\\\\'Y | |
| A03 | SWITCH BUTTON | |
| A04 | TRIANGULAR RULE | |
| A05 | HOLDER | |
| A06 | TCT SAW BLADE 190X20X24T | |
| A07 | SOCKET WRENCH | |
| A08 | HEX. WRENCH 2.5 | |
| E03 | SUB LEVER | |
| E04 | PAN HEAD SCREW M4X10 | |
| E05 | COMPRESSION SPRING 6 | |
| E06 | GUARD ASS\\\\\'Y INC. 38,40,197,198,199 |
