| П-п | Арт | Название |
|---|---|---|
| 1 | TAPPING SCREW 4X18 | |
| 2 | REAR COVER | |
| 3 | TAPPING SCREW 4X18 | |
| 4 | CONTROLLER | |
| 5 | NOISE SUPPRESSOR | |
| 6 | PAN HEAD SCREW M6X50 | |
| 7 | MOTOR HOUSING COMPLETE | |
| 8 | CARBON BRUSH CB-153 | |
| 9 | BRUSH HOLDER CAP 6.5-13.5 | |
| 10 | NAME PLATE LS1214 | |
| 11 | FIELD ASS\\\'Y 220-240V | |
| 12 | TAPPING SCREW 5X75 | |
| 13 | BAFFLE PLATE | |
| 14 | BALL BEARING 6000LLB | |
| 15 | INSULATION WASHER | |
| 16 | ARMATURE ASS\\\'Y 220V INC. 14,15,17 | |
| 17 | FAN 80 | |
| 18 | PAN HEAD SCREW M5X16 | |
| 19 | BEARING RETAINER 94 | |
| 20 | BALL BEARING 6003LLB | |
| 21 | RETAINING RING S-17 | |
| 22 | RING SPRING 8 | |
| 23 | PIN 6 | |
| 24 | COMPRESSION SPRING 7 | |
| 25 | STOP RING E-5 | |
| 26 | FLAT WASHER 6 | |
| 27 | RING 6 | |
| 28 | LINK PLATE | |
| 29 | HEX. SOCKET HEAD BOLT M6X20 | |
| 30 | FLAT WASHER 6 | |
| 31 | RING 6 | |
| 32 | SPRING HOLDER | |
| 33 | COMPRESSION SPRING 34 | |
| 34 | LOCK PIN 8 | |
| 35 | ROD HOLDER | |
| 36 | TAPPING SCREW CT 4X16 | |
| 37 | LOCK LEVER (NEW) | |
| 38 | HEX.SOCKET HEAD BOLT M4X8 (NEW) | |
| 39 | STOP RING E-6 | |
| 40 | ROD 8 | |
| 41 | TORSION SPRING 8 | |
| 42 | CAP | |
| 43 | PAN HEAD SCREW M4X10 | |
| 44 | LOCK PLATE | |
| 47 | SWITCH BUTTON | |
| 48 | HANDLE SET INC. 62 | |
| 49 | CORD GUARD 9.3-90 | |
| 50 | POWER SUPPLY CORD 1.0-2-2.5 | |
| 51 | STRAIN RELIEF | |
| 52 | TAPPING SCREW 4X18 | |
| 53 | CAM | |
| 54 | LOCK OFF LEVER | |
| 56 | COMPRESSION SPRING 3 | |
| 57 | NOISE SUPPRESSOR | |
| 58 | SWITCH TG70B | |
| 59 | SWITCH V-15-2A5 | |
| 60 | SWITCH LEVER | |
| 61 | TAPPING SCREW 4X18 | |
| 62 | HANDLE SET INC. 48 | |
| 63 | HEX. BOLT M8X45 | |
| 64 | RUBBER RING 6 | |
| 65 | PAN HEAD SCREW M6X16 | |
| 66 | GRIP | |
| 67 | GRIP HOLDER | |
| 68 | PAN HEAD SCREW M6X16 | |
| 69 | PAN HEAD SCREW M4X10 | |
| 70 | DUST NOZZLE (NEW) | |
| 71 | O RING 35 | |
| 72 | PAN HEAD SCREW M4X10 | |
| 73 | SCREW M6X43 | |
| 74 | URETHANE RING 5 | |
| 75 | STOPPER ARM | |
| 76 | STOPPER ARM PLATE | |
| 77 | MAKITA LOGO (NEW) | |
| 78 | BLADE CASE (NEW) | |
| 79 | GUARD PLATE (NEW) | |
| 80 | GUARD (NEW) | |
| 81 | BALL BEARING 608LLB | |
| 82 | RETAINING RING S-14 | |
| 83 | SPIRAL BEVEL GEAR 35 | |
| 84 | RUBBER RING 20 | |
| 85 | FLAT WASHER 14 | |
| 86 | O RING 54 | |
| 87 | BEARING BOX | |
| 88 | KEY 4 | |
| 89 | SPINDLE | |
| 90 | BALL BEARING 6203DDW | |
| 91 | BEARING RETAINER 66 | |
| 92 | RING 16 | |
| 93 | PAN HEAD SCREW M5X16 | |
| 94 | FLANGE 61 | |
| 95 | RING 16 | |
| 96 | FLANGE 61 | |
| 97 | HEX. FRANGE HEAD BOLT M10X20 | |
| 98 | CENTER PLATE | |
| 99 | CENTER COVER | |
| 100 |  |
HEX. FLANGE HEAD BOLT M8X12 |
| 101 |  |
FLAT HEAD SCREW M5 |
| 102 |  |
TORSION SPRING 45 |
| 103 |  |
SAFETY COVER (NEW) |
| 104 |  |
FLAT WASHER 6 |
| 105 |  |
PAN HEAD SCREW M5X12 |
| 106 |  |
PIN 16-113 (NEW) |
| 107 |  |
HEX. LOCK NUT M8-13 |
| 108 |  |
FLAT WASHER 8 |
| 109 |  |
ARM (NEW) |
| 110 |  |
STOPPER PIN |
| 111 |  |
O RING 7 |
| 112 |  |
STRAIN RELIEF |
| 113 |  |
TAPPING SCREW BIND CT 4X12 |
| 114 |  |
KNOB 20 |
| 115 |  |
H.S.SET SCREW(FLAT POINT)M6X10 |
| 116 |  |
HEX. BOLT M8X28 |
| 117 |  |
HEX. BOLT M8X20 |
| 118 |  |
STEEL BALL 10 |
| 119 |  |
GUIDE PLATE |
| 120 |  |
TORSION SPRING 28 |
| 121 |  |
INDICATION PLATE |
| 122 |  |
PAN HEAD SCREW M4X10 |
| 123 |  |
COMPRESSION SPRING 5 |
| 124 |  |
H.S.SET SCREW(FLATPOINT)M12X12 |
| 125 |  |
ARM HOLDER COMPLETE |
| 126 |  |
HEX. BOLT M10X100 |
| 127 |  |
PAN HEAD SCREW M4X10 |
| 128 |  |
LEVER 100 |
| 129 |  |
HEX. NUT M10-17 |
| 130 |  |
FLAT WASHER 10 |
| 131 |  |
COMPRESSION SPRING 5 |
| 132 |  |
SQUARE ROD COMPLETE |
| 133 |  |
HEX. BOLT M6X35 |
| 134 |  |
TURN BASE COMPLETE |
| 135 |  |
BEARING BOX B COMPLETE |
| 136 |  |
HEX. SOCKET HEAD BOLT M8X30 |
| 137 |  |
FLAT WASHER 8 |
| 138 |  |
HEX. BOLT M8X40 |
| 139 |  |
KERF BOARD |
| 140 |  |
TAPPING SCREW BIND CT 4X12 |
| 141 |  |
PAN HEAD SCREW M4X8 |
| 142 |  |
HEX. LOCK NUT M6-10 |
| 143 |  |
SUB FENCE PLATE |
| 144 |  |
SUB FENCE COMPLETE |
| 145 |  |
HEX. BOLT M8X30 |
| 146 |  |
GUIDE FENCE |
| 147 |  |
COUNTERSUNK HEAD SCREW M6X35 |
| 148 |  |
FLAT WASHER 6 |
| 149 | SCREW M6X10 | |
| 150 | TAPPING SCREW BIND CT 4X12 | |
| 151 | MITER SCALE PLATE | |
| 152 | SCREW M8X320 | |
| 153 | HEX. NUT M8 | |
| 154 | GRIP 40 | |
| 155 | FLAT WASHER 8 | |
| 156 | KNOB 48 COMPLETE | |
| 157 | CAP | |
| 158 | PIN 9-200 | |
| 159 | CAP 10 | |
| 160 | COIL SPRING | |
| 161 | LOCK PIN | |
| 162 | FLAT WASHER 6 | |
| 163 | COMPRESSION SPRING 6 | |
| 164 | STOP RING E-5 | |
| 165 | PIN HOLDER | |
| 166 | TAPPING SCREW CT 4X16 | |
| 167 | SLIDE STOPPER | |
| 168 | PAN HEAD SCREW M6 | |
| 169 | PIN 5 | |
| 170 | TURN STOPPER | |
| 171 | STOPPER HOLDER | |
| 172 | TAPPING SCREW CT 4X16 | |
| 173 | TAPPING SCREW BIND CT 4X12 | |
| 174 | POINTER | |
| 175 | SLIDE PLATE | |
| 176 | TAPPING SCREW CT 4X16 | |
| 177 | LEAF SPRING | |
| 178 | SCREW M6X10 | |
| 179 | BASE COMPLETE | |
| 180 | CAP 20 | |
| 181 | FLAT WASHER 25 | |
| 182 | STOPPER | |
| A01 | DUST BAG ASSY (NEW) | |
| A02 | VISE ASS\\\'Y | |
| A03 | SUB FENCE R COMPLETE | |
| A04 | SWITCH BUTTON | |
| A05 | TRIANGULAR RULE | |
| A06 | SCREW M6X10 | |
| A07 | HOLDER 255 | |
| A08 | TCT SAW BLADE 305X30X70T | |
| A09 | SOCKET WRENCH 13 |
