| П-п | Арт | Название |
|---|---|---|
| 1 | SHAFT LOCK | |
| 2 | BAFFLE PLATE | |
| 3 | O RING 32 | |
| 4 | BALL BEARING 6002LLB | |
| 5 | FAN 92 | |
| 6 | ARMATURE ASS\\\'Y 220V INC. 5,7,8 | |
| 7 | INSULATION WASHER | |
| 8 | BALL BEARING 6200LB | |
| 9 | PAN HEAD SCREW M5X65 | |
| 10 | RUBBER PIN 4 | |
| 11 | FIELD ASS\\\'Y 220V | |
| 13 | MOTOR HOUSING COMPLETE INC. 10 | |
| 14 | RIVET 0-5 | |
| 15 | NAME PLATE LS1440 | |
| 16 | #ИМЯ? | |
| 17 | PAN HEAD SCREW M4X30 | |
| 18 | CARBON BRUSH CB-153 | |
| 19 | BRUSH HOLDER CAP 6.5-13.5 | |
| 20 | SWITCH SGE220RD-1 | |
| 21 | PAN HEAD SCREW M4X6 | |
| 22 | HANDLE COVER | |
| 23 | NOISE SUPPRESSOR | |
| 24 | POWER SUPPLY CORD 1.0-2-2.5 | |
| 25 | CORD GUARD 8-90 | |
| 26 | CLAMP BASE COMPLETE | |
| 27 | STRAIN RELIEF | |
| 28 | PAN HEAD SCREW M4X18 | |
| 29 | CLAMP COVER | |
| 30 | PAN HEAD SCREW M4X16 | |
| 31 | GEAR HOUSING COMPLETE | |
| 32 | NEEDLE BEARING 1212 | |
| 33 | RETAINING RING S-20 | |
| 34 | HELICAL GEAR 41 | |
| 35 | BEARING BOX | |
| 36 | BALL BEARING 6204LLB | |
| 37 | THIN WASHER 20 | |
| 38 | SPINDLE | |
| 39 | BEARING RETAINER 72 | |
| 40 | COUNTERSUNK HEAD SCREW M5X20 | |
| 41 | INNER FLANGE 90 | |
| 42 | OUTER FLANGE 90 | |
| 43 | HEX. FLANGE HEAD BOLT M8X20 | |
| 44 | HEX. NUT M6 | |
| 45 | SPRING WASHER 6 | |
| 46 | BLADE CASE COMPLETE | |
| 47 | HEX. FLANGE HEAD BOLT M8X12 | |
| 48 | SPRING 30 | |
| 49 | SAFETY COVER | |
| 50 | CENTER PLATE | |
| 51 | CAP SQUARE NECK BOLT M6X12 | |
| 52 | PAN HEAD SCREW M5X10 | |
| 53 | BLADE STOPPER | |
| 54 | #ИМЯ? | |
| 55 | FLAT WASHER 10 | |
| 56 | #ИМЯ? | |
| 57 | RING 10 | |
| 58 | GUIDE ARM | |
| 59 | FLAT WASHER 8 | |
| 60 | KEY 4 | |
| 61 | PAN HEAD SCREW M4X14 | |
| 62 | #ИМЯ? | |
| 63 | CUSHION | |
| 64 | -SCREW (FLAT POINT)M10X80 | |
| 65 | FLAT WASHER 10 | |
| 66 | HEX. NUT M10 | |
| 67 | HEX. BOLT M10X30 | |
| 68 | GUIDE RULE | |
| 69 | SUPPORTER | |
| 70 | HEX. SOCKET HEAD BOLT M6X20 | |
| 71 | SET SCREW M10 | |
| 72 | HEX. BOLT M16 | |
| 73 |  |
FLAT WASHER 16 |
| 74 |  |
ARM COMPLETE |
| 75 |  |
TORSION SPRING 33 |
| 76 |  |
HANDLE LATCH |
| 77 |  |
WAVE WASHER 8 |
| 78 |  |
#ИМЯ? |
| 79 |  |
FLAT WASHER 16 |
| 80 |  |
HEX. NUT M16-24 |
| 81 |  |
FENCE PLATE |
| 82 |  |
KERF BOARD |
| 83 |  |
SET PLATE |
| 84 |  |
HOLDER |
| 85 |  |
SCREW M6X13 |
| 86 |  |
PAN HEAD SCREW M6X14 |
| 87 |  |
FLAT WASHER 6 |
| 88 |  |
VISE PLATE |
| 89 |  |
FLAT WASHER 12 |
| 90 |  |
NUT HOLDER |
| 91 |  |
SET PLATE |
| 92 |  |
PROTECTER |
| 93 |  |
RELEASE NUT R |
| 94 |  |
RELEASE NUT L |
| 95 |  |
VISE ARM COMPLETE |
| 96 |  |
KNOB 45 |
| 97 |  |
PAN HEAD SCREW M5X14 |
| 98 |  |
GRIP 37 |
| 99 |  |
PAN HEAD SCREW M4X8 |
| 100 |  |
INDICATION LABEL |
| 101 |  |
PLATE |
| 102 |  |
LATCH PIN |
| 103 |  |
PAN HEAD SCREW M5X35 |
| 104 |  |
HEX. BOLT M8X35 |
| 105 |  |
LEAF SPRING |
| 106 |  |
LATCH SPRING |
| 107 |  |
TURNING STAY |
| 108 |  |
PAN HEAD SCREW M5X16 |
| 109 |  |
BASE COMPLETE |
| 110 |  |
HOLDER |
| 111 |  |
HEX. SOCKET HEAD BOLT M10X40 |
| 112 |  |
SPRING WASHER 10 |
| 113 |  |
TURN BASE |
| 114 |  |
FLAT WASHER 10 |
| 115 |  |
RUBBER RING 12 |
| 116 |  |
FLAT WASHER 6 |
| 117 |  |
PAN HEAD SCREW M5X14 |
| 118 |  |
WASHER 15 |
| 400 |  |
SOCKET WRENCH 13 |
| 402 |  |
DUST BAG ASS\\\'Y INC. 403 |
| 403 |  |
FASTENER |
| 500 |  |
VISE ASS\\\'Y INC. 86-97 |
| 900 |  |
TUBE HOLDER |
| 901 | PAN HEAD SCREW M4X8 | |
| 908 | LOCK LEVER | |
| 909 | COMPRESSION SPRING 9 | |
| 910 | LOCK PLATE | |
| 911 | #ИМЯ? | |
| 912 | CHOKE COIL | |
| 913 | PROTECTOR R | |
| 914 | PROTECTOR L | |
| 915 | GUARD | |
| 916 | SAFETY COVER | |
| 917 | TAPPING SCREW 4X14 | |
| 918 | TAPPING SCREW 4X14 | |
| 919 | PAN HEAD SCREW M4X8 | |
| 920 | H.S.SET SCREW(FLAT POINT)M6X8 | |
| 921 | SCREW M5X20 | |
| 922 | VISE ASS\\\'Y |
