9237 CB
9237 CB
| П-п | Арт | Название |
|---|---|---|
| 1 | SUPPORT ASS\\\'Y | |
| 2 | FIELD 220/240V | |
| 3 | BAFFLE PLATE | |
| 4 | BALL BEARING 608LLB | |
| 5 | INSULATION WASHER | |
| 6 | ARMATURE ASS\\\'Y 220/240V INC. 4,5,7 | |
| 7 | FAN 70 | |
| 8 | BEARING RETAINER 48 | |
| 9 | BALL BEARING 6201LLB | |
| 10 | RETAINING RING S-12 | |
| 11 | TAPPING SCREW 5X35 | |
| 12 | HEAD COVER | |
| 13 | PAN HEAD SCREW M4X12 | |
| 14 | PIN CAP | |
| 15 | COMPRESSION SPRING 8 | |
| 16 | PAN HEAD SCREW M5X16 | |
| 17 | PAN HEAD SCREW M5X12 | |
| 18 | GEAR HOUSING COMPLETE | |
| 19 | SHOULDER PIN 9 | |
| 20 | SPIRAL BEVEL GEAR 52 | |
| 21 | RETAINING RING R-32 | |
| 22 | BALL BEARING 6201LLB | |
| 23 | BEARING BOX | |
| 24 | TAPPING SCREW CT 4X16 | |
| 25 | SPINDLE COMPLETE | |
| 26 | PAD 165 | |
| 29 | TAPPING SCREW 5X70 | |
| 30 | INDICATION LABEL | |
| 31 | MAGNET SLEEVE | |
| 32 | STOP RING E-6 | |
| 33 | MOTOR HOUSING SET INC. 35 | |
| 34 | CARBON BRUSH CB-303 | |
| 35 | MAKITA LOGO LABEL | |
| 36 | BRUSH HOLDER CAP 7-11 | |
| 37 | 9237CB NAME PLATE | |
| 38 | DIAL 28 | |
| 39 | CONTROLLER 200-250V | |
| 40 | RIVET 2 | |
| 41 | COMPRESSION SPRING 3 | |
| 42 | HANDLE SET INC. 54 | |
| 43 | NOISE SUPPRESSOR | |
| 44 | CHOKE COIL | |
| 45 | SWITCH | |
| 49 | TAPPING SCREW 4X18 | |
| 50 | STRAIN RELIEF | |
| 51 | CORD GUARD 10 | |
| 52 | POWER SUPPLY CORD 1.0-2-4.0 | |
| 53 | TAPPING SCREW 4X18 | |
| 54 | HANDLE SET INC. 42 | |
| 55 | DUST COVER | |
| 56 | TAPPING SCREW 4X18 | |
| A01 | HEX. SOCKET HEAD BOLT M8X25 | |
| A02 | HEX. WRENCH 6 | |
| A03 | SLEEVE 18 | |
| A04 | LOOP HANDLE | |
| A05 | WOOL PAD 180 |
