01 Генератор в сборе
01 Генератор в сборе
| П-п | Арт | Название |
|---|---|---|
| 1 | CROSS BANDING | |
| 2 | SCREW M5x14 | |
| 3 | RIGHT SIDE COVER ASSEMBLY | |
| 4 | NUT M6 | |
| 5 | NUT M5 | |
| 6 | BASE ASSEMBLY | |
| 7 | BASE MOUNTING4 | |
| 8 | BOLT M6X22 | |
| 9 | NUT M6 | |
| 10 | BOLT M6X12 | |
| 11 | CONTROL UNIT | |
| 12 | CLIP | |
| 13 | BOLT M6X15 | |
| 14 | STOPPER | |
| 15 | BOLT M6 | |
| 16 | TAPPING SCREW | |
| 17 | RUBBER PLUG | |
| 18 | PARALLEL POWER UNIT | |
| 19 | OUTPUT PANEL BOX | |
| 20 | BOLT M4 | |
| 21 | CLIP | |
| 22 | AC BREAKER 13.3A (CSA) | |
| 23 | RECEPTACLE 5-20R | |
| 24 | BOLT M5X14 | |
| 25 | BOLT M2 | |
| 26 | OUTPUT PANEL | |
| 27 | NUT M5 | |
| 28 | FLAT WASHER ⌀3 | |
| 29 | SPRING WASHER ⌀3 | |
| 30 | SCREW M3x6 | |
| 31 | PARALLEL TERMINAL | |
| 32 | SCREW M2x10 | |
| 33 | SCREW M4x14 | |
| 34 | COMMUNICATION RECEPTACLE | |
| 35 | SPRING WASHER ⌀4 | |
| 36 | FLAT WASHER ⌀4 | |
| 37 | CHOCK CABLE ASSEMBLY | |
| 38 | SCREW M4x12 | |
| 39 | FUEL COCK KNOB | |
| 40 | ENGINE SWITCH | |
| 41 | CONTROL PANEL | |
| 42 | IGNITION ASSEMBLY | |
| 43 | MAGNET RING ASSEMBLY | |
| 44 | CONTROL PANEL BOX | |
| 45 | GUIDE-ROPE HANDLE | |
| 46 | NUT M6 | |
| 47 | FRONT COVER ASSEMBLY | |
| 48 | LEFT SIDE COVER ASSEMBLY | |
| 49 | ENGINE | |
| 50 | FUEL COCK COMP. | |
| 51 | FUEL TANK ASSEMBLY | |
| 52 | COVER,REAR 1 | |
| 53 | FUEL FILTER COMP. | |
| 54 | MAINTENANCE COVER | |
| 55 | SCREW M6x14 | |
| 56 | FUEL GUIDE PLATE | |
| 57 | SEAL,PLUG CAP | |
| 58 | FUEL TANK CAP COMP. | |
| 59 | FLAT WASHER ⌀6 | |
| 60 | HOLDER ASSEMBLY | |
| 61 | COVER,TOP | |
| 62 | BOLT M5x13 |
