| П-п | Арт | Название |
|---|---|---|
| 1 | HEX. SOCKET HEAD BOLT M10X25 | |
| 2 | OUTER FLANGE 65 | |
| 3 | INNER FLANGE 65 | |
| 4 | COUNTERSUNK HEAD SCREW M5X16 | |
| 5 | BEARING RETAINER 42-68 | |
| 6 | SAFETY COVER | |
| 7 | TENSION SPRING 8 | |
| 8 | BALL BEARING 6204DDW | |
| 9 | ROLLER PIN 6 | |
| 10 | ROLLER 20 | |
| 11 | ROLLER 20 | |
| 12 | ROLLER PIN 6 | |
| 13 | HEX. SOCKET HEAD BOLT M8X16 | |
| 14 | FLAT WASHER 8 | |
| 15 | RIVING KNIFE | |
| 16 | RIVING KNIFE HOLDER | |
| 17 | THICKNESS RING | |
| 18 | PAN HEAD SCREW M5X16 | |
| 19 | BEARING BOX | |
| 20 | LOCK SLEEVE | |
| 21 | SPINDLE | |
| 22 | LOCK SPRING 20 | |
| 23 | LOCK SPRING 27 | |
| 24 | HELICAL GEAR 57 | |
| 25 | BALL BEARING 6001 | |
| 26 | RETAINING RING S-12 | |
| 27 | LEVER 54 | |
| 28 | RING SPRING 12 | |
| 29 | HEX. NUT M8 | |
| 30 | PAN HEAD SCREW M5X40 | |
| 31 | TAPPING SCREW 5X25 | |
| 32 | HANDLE SET INC. 39 | |
| 33 | LOCK-OFF BUTTON | |
| 34 | COMPRESSION SPRING 4 | |
| 35 | SWITCH LEVER | |
| 36 | SWITCH TG70B | |
| 37 | NOISE SUPPRESSOR | |
| 38 | CONTROLLER 200/220/240V | |
| 39 | HANDLE SET INC. 32 | |
| 40 | PIPE 9 | |
| 41 | FLAT WASHER 8 | |
| 42 | CAP SQUARE NECK BOLT M8X98 | |
| 43 | TAPPING SCREW 4X18 | |
| 44 | STRAIN RELIEF | |
| 45 | CORD GUARD 9.3-90 | |
| 46 | POWER SUPPLY CORD 1.0-2-5.0 | |
| 47 | PAN HEAD SCREW M5X12 | |
| 48 | LEVER 110 | |
| 49 | STEEL BALL 7.9 | |
| 50 | COMPRESSION SPRING 7 | |
| 51 | BLADE CASE COMPLETE | |
| 52 | COMPRESSION SPRING 5 | |
| 53 | SHAFT LOCK | |
| 54 | GUIDE ROD | |
| 55 | TAPPING SCREW BIND CT 4X12 | |
| 56 | FELT | |
| 57 | PLATE | |
| 58 | STRAIN RELIEF | |
| 59 | TAPPING SCREW CT 4X16 | |
| 60 | PIN 10 | |
| 61 | CUSHION | |
| 62 | WIRE ROPE | |
| 63 | ARM | |
| 64 | TORSION SPRING 23 | |
| 65 | CAM PLATE | |
| 66 | PIN 12 | |
| 67 | BLADE CASE COVER | |
| 68 | MAKITA LABEL | |
| 69 | TAPPING SCREW BIND CT 5X20 | |
| 70 | BALL BEARING 6002DDW | |
| 71 | FAN 74 | |
| 72 | BAFFLE PLATE | |
| 73 | ARMATURE ASS\\\\\'Y 220/240V INC. 81,82 | |
| 74 | PAN HEAD SCREW M5X90 | |
| 75 | FIELD ASS\\\\\'Y 220-240V | |
| 76 | NAME PLATE 5143R | |
| 77 | PAN HEAD SCREW M5X65 | |
| 78 | CARBON BRUSH CB-203 | |
| 79 | BRUSH HOLDER CAP 7-18 | |
| 80 | MOTOR HOUSING 200-240V | |
| 81 | BALL BEARING 629LLB | |
| 82 | INSULATION WASHER | |
| 83 | CAP SQUARE NECK BOLT M8X50 | |
| 84 | ANGULAR PLATE GUIDE | |
| 85 | TAPPING SCREW BIND CT 5X20 | |
| 86 | FLAT WASHER 8 | |
| 87 | WING NUT | |
| 88 | GRIP | |
| 89 | TAPPING SCREW 5X25 | |
| 90 | PIN 8 | |
| 91 | H.S.SET SCREW(CUP POINT)M4X5 | |
| 92 | TAPPING SCREW BIND CT 4X12 | |
| 93 | ANGULAR PLATE | |
| 94 | STOP RING E-6 | |
| 95 | POINTER | |
| 96 | TAPPING SCREW BIND CT 5X20 | |
| 97 | + BINDING HEAD SCREW M5 | |
| 98 | LINK | |
| 99 | STOP RING E-6 | |
| 100 | PIN 8 | |
| 101 | BASE BRIDGE | |
| 102 | H.S.SET SCREW(FLAT POINT)M6X10 | |
| 103 | TAPPING SCREW BIND CT 5X20 | |
| 104 | DEPTH GUIDE | |
| 105 | H.S.SET SCREW(CUP POINT)M4X5 | |
| 106 | SCREW M6X15 | |
| 107 | BASE | |
| 108 | H.S.SET SCREW(FLAT POINT)M6X10 | |
| 109 | H.S.SET SCREW(FLAT POINT)M6X10 | |
| 110 | TAPPING SCREW BIND CT 4X12 | |
| 113 | PACKING | |
| A01 | T.C.T. SAW BLADE 355X20TX30 | |
| A02 | GUIDE RULE | |
| A03 | HEX. WRENCH 6 | |
| E01 | SWITCH V-15-2A5 | |
| E03 | INSULATED CONNECTOR 5.5-SD | |
| E04 | INSULATED RECEPTACLE DF1.25 | |
| E05 | CONNECTOR 2-SD | |
| E06 | INSULATED RECEPTACLE DF2-187A | |
| E08 | JOINT |
