| П-п | Арт | Название |
|---|---|---|
| 1 |  |
SHOE |
| 2 |  |
INSULATION COVER |
| 3 |  |
PROTECTOR (NEW) |
| 4 |  |
RETAINING RING (EXT) 18 NEW |
| 5 |  |
DRIVING SLEEVE (NEW) |
| 6 |  |
PIN 3 |
| 7 |  |
GUIDE SLEEVE (NEW) |
| 8 |  |
DRIVING SLEEVE GUIDE |
| 9 | SLEEVE | |
| 10 | PUSH PLATE | |
| 11 | COMPRESSION SPRING 2 | |
| 12 | TORSION SPRING 17 | |
| 13 | SHOULDER SLEEVE 14 | |
| 14 | X RING 14 | |
| 15 | PAN HEAD SCREW M5X16 | |
| 16 | CAP | |
| 17 | STOP RING E-6 | |
| 18 | GEAR HOUSING COVER COMPLETE | |
| 19 | STOP RING E-6 | |
| 20 | SLIDER SUPPORT COMPLETE | |
| 21 | COMPRESSION SPRING 5 | |
| 22 | SEAL PLATE 14 | |
| 23 | PLANE BEARING 14A | |
| 24 | SLIDER (NEW) | |
| 25 | SLIDE PLATE | |
| 26 | GEAR HOUSING | |
| 27 | BEARING COMPLETE | |
| 28 | PLATE B | |
| 29 | PAN HEAD SCREW M5X16 (NEW) | |
| 30 | HEX.SOCKET HEAD BOLT M5X8 | |
| 31 | SPRING PIN 3-8 | |
| 32 | PAN HEAD SCREW M5X16 | |
| 33 | BEARING BOX | |
| 34 | BALL BEARING 6001LLB | |
| 35 | GEAR PLATE | |
| 36 | O RING 62 | |
| 37 | TORQUE LIMITER COMPLETE | |
| 38 | TAPPING SCREW 5X35 (NEW) | |
| 39 | TORXSOCKET C.S. HEADSCREW M6X16 (NEW) | |
| 40 | SHOE GUIDE | |
| 41 | LEAF SPRING B | |
| 42 | PAN HEAD SCREW M5X16 (NEW) | |
| 43 | PLATE A | |
| 44 | HEX.SOCKET HEAD BOLT M6X14 | |
| 45 |  |
CRANK CAM COMPLETE |
| 46 |  |
RING 21 |
| 47 |  |
COUNTER WEIGHT |
| 48 |  |
CRANK BASE COMPLETE |
| 49 |  |
GUIDE PLATE |
| 50 |  |
BALL BEARING 6003LLB |
| 51 |  |
TORX SOCKET HEAD SCREW M5X14 |
| 52 |  |
NEEDLE BEARING 710 |
| 54 |  |
STOPPER |
| 55 |  |
COMPRESSION SPRING 5 |
| 56 |  |
LEVER 20 |
| 57 |  |
O RING 5 |
| 58 |  |
O RING 5 |
| 59 |  |
PLATE C |
| 60 |  |
SEAL RING |
| 61 |  |
PIN 7 |
| 62 |  |
SHIFT BUTTON |
| 63 |  |
LEAF SPRING A |
| 64 |  |
PIN 3 |
| 65 |  |
COMPRESSION SPRING 6 |
| 66 |  |
SHOULDER PIN 5 |
| 67 |  |
RETAINING RING S-12 |
| 68 |  |
FLAT WASHER 12 |
| 69 |  |
BALL BEARING 6001DDW |
| 70 |  |
FLAT WASHER 12 |
| 71 |  |
BEARING RETAINER A |
| 72 |  |
FAN 70 |
| 73 |  |
ARMATURE ASS\\\'Y 220-240V INC.72,74,75 |
| 74 |  |
INSULATION WASHER |
| 75 |  |
BALL BEARING 608ZZ |
| 76 |  |
TAPPING SCREW 5X45 (NEW) |
| 77 |  |
BAFFLE PLATE |
| 78 |  |
FIELD ASS\\\'Y 220-240V |
| 79 |  |
MOTOR HOUSING COMPLETE |
| 80 |  |
SWITCH TG71ARS-1 (NEW) |
| 81 |  |
TAPPING SCREW 4X18 |
| 82 |  |
HANDLE SET INC. 100 |
| 83 |  |
POWER SUPPLY CORD 1.0-2-4.0 |
| 84 |  |
TAPPING SCREW 4X18 |
| 85 |  |
STRAIN RELIEF (NEW) |
| 86 |  |
CORD GUARD 10 |
| 87 |  |
NOISE SUPPRESSOR |
| 88 |  |
NOISE SUPPRESSOR |
| 89 |  |
CHOKE COIL |
| 92 |  |
CONTROLLER |
| 93 |  |
O RING 17 |
| 94 |  |
DIAL |
| 95 |  |
SLEEVE |
| 96 |  |
RUBBER BAND |
| 97 |  |
JR3070CT NAME PLATE |
| 98 |  |
CARBON BRUSH CB-303 |
| 99 |  |
BRUSH HOLDER CAP 7-11 |
| 100 |  |
HANDLE SET INC.82 |
| 101 |  |
GEAR HOUSING COVER ASSEMBLY INC.3-14,16-20,22-25,27-29,42,43,54-59,61-66 |
| A01 |  |
PLASTIC CARRYING CASE (NEW) |
| A02 |  |
RECIPRO SAW BLADE FOR METAL (NEW) |
| A03 |  |
RECIPRO SAW BLADE FOR PLYWOOD |
| A04 |  |
RECIPRO SAW BLADE FOR WOOD |
