| П-п | Арт | Название |
|---|---|---|
| 1 |  |
BELT GUARD |
| 2 |  |
BOLT M8X16 |
| 3 |  |
BOLT M8X16 |
| 4 |  |
BOLT M8X16 |
| 5 |  |
HEX BOLT M10X20 |
| 6 |  |
SPRING WASHER 10 |
| 7 |  |
WASHER 10X38X5 |
| 8 |  |
PULLEY |
| 9 |  |
KEY 8 X 50 |
| 10 |  |
INSIDE HEX BOLT M10X35 |
| 11 |  |
WASHER 10 |
| 12 |  |
BEARING LF205 |
| 13 |  |
WASHER 10 |
| 14 |  |
SPRING WASHER 10 |
| 15 |  |
NUT 10 |
| 16 |  |
REAR AXIS |
| 17 |  |
NUT 10 |
| 18 |  |
NUT 10 |
| 19 |  |
WASHER 10 |
| 20 |  |
BEARING LF205 |
| 21 |  |
WASHER 10 |
| 22 |  |
INSIDE HEX BOLT M10X35 |
| 23 |  |
BLADE FLANGE (INNER) |
| 24 |  |
KEY 5 X 18 |
| 25 |  |
PIN ø10X35 |
| 26 |  |
LASER WELDING DIAMOND BLADE |
| 27 |  |
BLADE FLANGE (OUTER) |
| 28 |  |
WASHER 12x32 |
| 29 |  |
SPRING WASHER 12 |
| 30 |  |
BOLT M8X16 |
| 31 |  |
HEX BOLT M12X25 |
| 32 |  |
|
| 33 |  |
|
| 34 |  |
HEX NUT M8 |
| 35 |  |
WASHER 8 |
| 36 |  |
PROTECTIVE MAT |
| 37 |  |
WASHER 10x32 |
| 38 |  |
SPRING WASHER 10 |
| 39 |  |
HEX BOLT M10X20 |
| 40 |  |
WASHER 8 |
| 41 | HEX BOLT M8X25 | |
| 42 | BLADE GUARD | |
| 43 | ENGINE | |
| 44 | PULLEY FOR ENGINE | |
| 45 | WASHER 10 OR 8 | |
| 46 | KEY 5 X 18 | |
| 47 | SPRING WASHER 10 or 8 | |
| 48 | BOLT M10 OR M8 | |
| 49 |  |
BELT |
| 50 |  |
BOLT M10 |
| 51 |  |
SPRING WASHER 10 |
| 52 |  |
WASHER 10 |
| 53 |  |
WASHER 10x28 |
| 54 |  |
HEX BOLT M10X45 |
| 55 |  |
BOLT M8X16 |
| 56 |  |
FRONT PANEL BOARD |
| 57 |  |
BOLT M8X35 |
| 58 |  |
LIFTING HOOK |
| 59 |  |
PANEL BOARD |
| 60 |  |
WASHER 8 |
| 61 |  |
BOLT M8X16 |
| 62 |  |
SCREW ARBOR |
| 63 |  |
KEY 6 X 40 |
| 64 |  |
BEARING LF205 |
| 65 |  |
BOLT M8X25 |
| 66 |  |
PIN ø4 |
| 67 |  |
SHAFT SLEEVE |
| 68 |  |
WHEEL HANDLE |
| 69 |  |
HEX BOLT M8X25 |
| 70 |  |
SPRING WASHER 8 |
| 71 |  |
WASHER 8x32 |
| 72 |  |
LOCATING PIN |
| 73 |  |
SPRING |
| 74 |  |
BOLT M8X16 |
| 75 |  |
PLUM NUT M8 |
| 76 |  |
POSITION BRACKET |
| 77 |  |
HANDLE GRIP M10 (only semi-automatic） |
| 78 |  |
BOLT M8X20 (only semi-automatic） |
| 79 |  |
SPRING WASHER 8 (only semi-automatic） |
| 80 |  |
WASHER 8 (only semi-automatic） |
| 81 |  |
TURN HANDLE (only semi-automatic） |
| 82 |  |
WASHER 10 (only semi-automatic） |
| 83 |  |
SPRING WASHER 10 (only semi-automatic） |
| 84 |  |
NUT 10 (only semi-automatic） |
| 85 |  |
BOLT M8X10 (only semi-automatic） |
| 86 |  |
HEX BOLT M10X25 (only semi-automatic） |
| 87 |  |
WASHER 10 (only semi-automatic） |
| 88 |  |
BEARING FL204 (only semi-automatic） |
| 89 |  |
BOLT M8X16 |
| 90 |  |
WASHER 8 |
| 91 |  |
BOLT M8X16 |
| 92 |  |
BOLT M8X25 |
| 93 |  |
CABLE |
| 94 |  |
RUBBER HANDLE |
| 95 |  |
THROTTLE CONTROL |
| 96 |  |
HANDLE |
| 97 |  |
WATER TANK CLAMP |
| 98 |  |
PLUM BOLT M8X35 |
| 99 |  |
WATER TANK |
| 100 |  |
STUD BOLT WITH COMPOUND GASKET 4 |
| 101 |  |
INSIDE ANGLE FITTING 4 |
| 102 |  |
STUD BOLT 4 TO 6 |
| 103 |  |
QUICK JOINT |
| 104 |  |
WATERPIPE |
| 105 |  |
ANCHOR EAR |
| 106 |  |
HEX BOLT M8X20 |
| 107 |  |
WASHER 8x32 |
| 108 |  |
BEARING 6203 |
| 109 |  |
FRONT WHEEL |
| 110 |  |
BASE PLATE |
| 111 |  |
CORRUGATED GASKET 20 |
| 112 |  |
BEARING BLOCK A |
| 113 |  |
WASHER 8 |
| 114 |  |
INSIDE HEX BOLT M8X20 |
| 115 |  |
NUT 12 |
| 116 |  |
WASHER 12 |
| 117 |  |
WASHER 12 |
| 118 |  |
HEX BOLT M12X35 |
| 119 |  |
KEY 6 X 50 (only semi-automatic） |
| 120 |  |
WASHER 8x30 (only semi-automatic） |
| 121 |  |
SPRING WASHER 8 (only semi-automatic） |
| 122 |  |
HEX BOLT M8X20 (only semi-automatic） |
| 123 |  |
ENDLESS SCREW (only semi-automatic） |
| 124 |  |
POINTER |
| 125 |  |
NUT 12 |
| 126 |  |
POINTER WHEEL |
| 127 |  |
WASHER 12 |
| 128 |  |
SPRING WASHER 12 |
| 129 |  |
NUT 12 |
| 130 |  |
WASHER 12 |
| 131 |  |
NUT 12 |
| 132 |  |
NUT 12 |
| 133 |  |
BOLT M8X16 |
| 134 |  |
BOLT M8X16 |
| 135 |  |
SIDE PLATE B |
| 136 |  |
PLUM BOLT ø32XM8X8 |
| 137 |  |
HEX BOLT M8X35 |
| 138 |  |
SCALE |
| 139 |  |
BIG BASE PLATE |
| 140 |  |
LOCKNUT M8 |
| 141 |  |
|
| 142 |  |
POINTER |
| 143 |  |
NUT 8 |
| 144 |  |
HEX BOLT M8X45 |
| 145 |  |
NUT 8 |
| 146 |  |
CONNECTING STEM |
| 147 |  |
REAR PLATE |
| 148 |  |
BOLT M8X16 |
| 149 |  |
MAIN SHAFT (only semi-automatic） |
| 150 |  |
FRONT PLATE |
| 151 |  |
BOLT M8X16 |
| 152 |  |
HEX BOLT M10X35 (only semi-automatic） |
| 153 |  |
SPRING WASHER 10 (only semi-automatic） |
| 154 |  |
WASHER 10 (only semi-automatic） |
| 155 |  |
BEARING FL204 (only semi-automatic） |
| 156 |  |
PEDAL (only semi-automatic） |
| 157 |  |
NUT 8 (only semi-automatic） |
| 158 |  |
HEX BOLT M8X20 (only semi-automatic） |
| 159 |  |
PLUG (only semi-automatic） |
| 160 |  |
BOLT M8X16 |
| 161 |  |
SIDE PLATE A |
| 162 |  |
BOLT M8X16 |
| 163 |  |
NUT 10 |
| 164 |  |
HEX BOLT M10X70 |
| 165 |  |
REAR AXIS |
| 166 |  |
KEY 8 X 20 (only semi-automatic） |
| 167 |  |
SLEEVE, WORM (only semi-automatic） |
| 168 |  |
WORM (only semi-automatic） |
| 169 |  |
WORM (only semi-automatic） |
| 170 |  |
RETAINER RING 30 (only semi-automatic） |
| 171 |  |
BEARING BLOCK B |
| 172 |  |
CORRUGATED GASKET 20 |
| 173 |  |
INSIDE HEX BOLT M8X20 |
| 174 |  |
REAR WHEEL |
| 175 |  |
BEARING 6204 |
| 176 |  |
WASHER 8x32 |
| 177 |  |
SPRING WASHER 8 |
| 178 |  |
HEX BOLT M8X20 |
