| П-п | Арт | Название |
|---|---|---|
| 1 |  |
ASSMY, AIR CLEANER COVER (SQUARE) |
| 2 |  |
FILTER, AIR CLEANER |
| 3 |  |
ASSMY, CARBURETOR MOUNTING SCREWS |
| 4 |  |
WASHER, WAVEY |
| 5 |  |
PIECE PLUS FOURNI.ANNULER VOTRE CDE |
| 6 |  |
CARBURETTOR |
| 7 | THROTTLE ADJUSTING ASSEMBLY WALBRO | |
| 8 | GASKET, CARBURETOR X1 | |
| 9 | ASSMY, PRIMER BULB & HOSE | |
| 10 | ASSMY, CARB MOUNT & REED PLATE | |
| 11 | ASSMY, REED VALVE | |
| 12 | PAD, REAR MOUNT PAD | |
| 13 | GASKET | |
| 14 | PIECE PLUS FOURNI.ANNULER VOTRE CDE | |
| 15 | PIECE PLUS FOURNI.ANNULER VOTRE CDE | |
| 16 | ASSMY, INNER BEARING ASSEMBLY | |
| 17 | SEAL, SEAL | |
| 18 | BEARING, OUTER | |
| 19 | ASSMY, FUEL TANK | |
| 20 | ASSMY, FUEL CAP W/RETAINER | |
| 21 | HOSE | |
| 22 | PUMP | |
| 23 | PAD, FRONT MOUNTING | |
| 24 | ASSMY, SHROUD ASSEMBLY | |
| 25 | HOLDER | |
| 26 | ASSMY, FLYWHEEL W/IMPROVED DOG | |
| 27 | NUT, SQUARE DRIVE | |
| 28 | PULLEY | |
| 29 | SPRING | |
| 30 | PULLEY RETAINER ASSEMBLY | |
| 31 | GUIDE, ROPE | |
| 32 | HANDLE, STARTER | |
| 33 | ROPE | |
| 34 | PIECE PLUS FOURNI.ANNULER VOTRE CDE | |
| 35 | CLAMP ASSEMBLY | |
| 36 | ASSMY, MODULE ASSEMBLY | |
| 37 | TAB. GROUND | |
| 38 | SPARK PLUG | |
| 39 | GASKET, MUFFLER | |
| 40 | PIECE PLUS FOURNI.ANNULER VOTRE CDE | |
| 41 | ASSMY, MUFFLER MOUNTING BOLTS | |
| 42 | PIECE PLUS FOURNI.ANNULER VOTRE CDE | |
| 43 | ASSMY, PISTON/ROD/RING | |
| 44 | GASKET, CYLINDER X1 |
