| П-п | Арт | Название |
|---|---|---|
| 1 | PAN HEAD SCREW M5X14 | |
| 2 | REAR COVER | |
| 3 | BEARING COVER 45 | |
| 4 | SCALE RING | |
| 5 | RUBBER PIN 4 | |
| 6 | MOTOR HOUSING COMPLETE | |
| INC. 5 | ||
| 7 | CARBON BRUSH CB-153 | |
| 8 | BRUSH HOLDER CAP 6.5-13.5 | |
| 9 | STAY | |
| 10 | FIELD ASS\\\'Y 220V | |
| 11 | BALL BEARING 6200LB | |
| 12 | INSULATION WASHER | |
| 13 | PAN HEAD SCREW M5X55 | |
| 14 | ARMATURE ASS\\\'Y 220V | |
| INC. 11,12,15 | ||
| 15 | FAN 76 | |
| 16 | FLAT WASHER 12 | |
| 17 | MOTOR BRACKET | |
| 18 | PAN HEAD SCREW M5X25 | |
| 19 | BALL BEARING 6201DDW | |
| 20 | BEARING RETAINER 40 | |
| 21 | PAN HEAD SCREW M5X14 | |
| 22 | COLLET CHUCK 12MM | |
| 23 | HANDLE SET | |
| INC. 41 | ||
| 24 | SWITCH HPAHR2-3S | |
| 26 | CORD GUARD 8-90 | |
| 27 | POWER SUPPLY CORD 1.00-2-5.0 | |
| 28 | PAN HEAD SCREW M5X20 | |
| 29 | PAN HEAD SCREW M4X28 | |
| 30 | PAN HEAD SCREW M4X18 | |
| 31 | STRAIN RELIEF | |
| 32 | PAN HEAD SCREW M4X6 | |
| 33 | LOCK PLATE | |
| 34 | NAME PLATE 3601B | |
| 35 | ROUTER BASE | |
| 36 | KNOB 52 | |
| 37 | PAN HEAD SCREW M5X10 | |
| 38 | WING BOLT M6X20 | |
| 39 | COMPRESSION SPRING 7 | |
| 40 | BASE PLATE | |
| 41 | HANDLE SET | |
| INC. 23 | ||
| 400 | STRAIGHT BIT 8X8 | |
| 401 | COLLET SLEEVE FOR 6 MM BIT | |
| 402 | COLLET SLEEVE FOR 8 MM BIT | |
| 403 | WRENCH 21 | |
| 404 | WRENCH 23 | |
| 405 | WING BOLT M6X20 | |
| 406 | COMPRESSION SPRING 7 | |
| 407 | STRAIGHT GUIDE | |
| 408 | ROD 10-180 | |
| 409 | TEMPLET GUIDE 16 | |
| 410 | WING BOLT M6X15 | |
| 411 | SPRING WASHER 6 | |
| 412 | FLAT WASHER 6 | |
| 414 | TRIMMER GUIDE HOLDER | |
| 415 | FLAT WASHER 6 | |
| 416 | WING BOLT M6X30 | |
| 417 | SPRING WASHER 6 | |
| 418 | SCREW M10X65 | |
| 419 | ROLL | |
| 420 | RING 10 | |
| 421 | PLATE HOLDER | |
| 422 | CAP SQUARE NECK BOLT M5X12 | |
| 423 | WING NUT M5 | |
| 424 | SPRING WASHER 5 | |
| 425 | PAN HEAD SCREW M4X10 | |
| 426 | FLEXIBLE HOSE DE | |
| 500 | STRAIGHT GUIDE ASS\\\'Y | |
| 501 | TRIMMER GUIDE ASS\\\'Y | |
| 900 | INC. 410-412,414-424 LINE FILTER | |
| 907 |  |
POWER SUPPLY CORD 0.75-3-0.3 |
