| П-п | Арт | Название |
|---|---|---|
| 1 | POWER SUPPLY CORD 1.0-2-2.5 | |
| 2 | CORD GUARD 8-85 | |
| 3 | NAME PLATE 3707 | |
| 4 | REAR COVER | |
| 5 | CASE | |
| 6 | TAPPING SCREW 4X18 | |
| 7 | CORD CLAMP | |
| 8 | BRUSH HOLDER CAP | |
| 9 | CARBON BRUSH CB-411 | |
| 10 | MOTOR REAR HOUSING INC. 25 | |
| 11 | FIELD ASSY 240V | |
| 12 | TAPPING SCREW 4X70 | |
| 17 | RUBBER RING 19 | |
| 18 | BALL BEARING 607DDW | |
| 19 | INSULATION WASHER | |
| 20 | ARMATURE ASSY 240V INC. 18,19,21,22 | |
| 21 | FAN 48 | |
| 22 | RETAINING RING S-15 | |
| 23 | BALL BEARING 6002DDW | |
| 24 | SWITCH | |
| 25 | MAKITA LABEL | |
| 26 | TERMINAL BLOCK | |
| 29 | + TAPPING SCREW M4X12 | |
| 30 | SUPPORTER | |
| 31 | TAPPING SCREW 4X35 | |
| 32 | MOTOR HOUSING COMPLETE | |
| 33 | COLLET CONE 6MM | |
| 34 | COLLET NUT 6 | |
| 35 | SCREW M6X25 | |
| 36 | SPRING WASHER 6 | |
| 37 | FLAT WASHER 6 | |
| 38 | BASE | |
| 39 | BASE PROTECTOR | |
| 40 | PIN 3 | |
| 41 | ROLLER W/O PIN | |
| 42 | HEX. LOCK NUT M5-8 | |
| 43 | FLAT WASHER 5 | |
| 44 | FLAT WASHER 6 | |
| 45 | SUPPORT PIN | |
| 46 | SPRING PIN 3-14 | |
| 47 | RUBBER CAP | |
| 48 | LOCK LEVER | |
| 49 | COUNTERSUNK HEAD SCREW M4X14 | |
| 50 | WAVE WASHER 23 | |
| A01 | TRIMMER GUIDE ASS\\\\\'Y INC A02-A08,A10 | |
| A02 | THUMB SCREW M6 | |
| A03 | + COUNTERSUNK HEAD SCREW M4X10 | |
| A04 | HOOK | |
| A05 | - FLAT HEAD SCREW M5 | |
| A06 | ROLLER 11 | |
| A07 | GUIDE HOLDER | |
| A08 | FLAT WASHER 6 | |
| A10 | THUMB SCREW M6X25 | |
| A11 | CAP SQUARE NECK BOLT M6X20 | |
| A12 | WAVE WASHER 6 | |
| A13 | TEMPLET GUIDE 10 | |
| A14 | WRENCH 10 | |
| A15 | WRENCH 17 | |
| A16 | WING NUT M6 | |
| A17 | FLAT WASHER 6 | |
| A18 | GUIDE PLATE | |
| A19 | STRAIGHT GUIDE | |
| A20 | STRAIGHT BITS 6 | |
| E01 | NOISE SUPPRESSOR |
