| П-п | Арт | Название |
|---|---|---|
| 1 |  |
Power cord & plug |
| 2 |  |
Cord protector |
| 3 |  |
Left housing |
| 4 |  |
Left volute case |
| 5 |  |
Rubber pad |
| 6 |  |
Self tapping screw |
| 7 |  |
Cable press board |
| 8 |  |
Terminal set |
| 9 |  |
Control PCB |
| 10 |  |
Inductance |
| 11 |  |
Switch Trigger |
| 12 |  |
Spring |
| 13 |  |
Capacitor |
| 14 |  |
Switch |
| 15 |  |
Spacing collar |
| 16 |  |
Push button |
| 17 |  |
Compression spring |
| 18 |  |
Aux.Handle Ass\\\'y |
| 19 |  |
Barrel shaped head 3 in 1 machine screw |
| 20 |  |
Aux.Handle cover |
| 21 |  |
Aux.Handle support |
| 22 |  |
Hexagonal locking nut |
| 23 |  |
Insulating cover |
| 24 |  |
Barrel shaped head machine screw |
| 25 |  |
Should belt ring |
| 26 |  |
Rubber cover |
| 27 |  |
Foam grip |
| 28 |  |
Self-tapping screw |
| 29 |  |
Rear cover |
| 30 |  |
Motor Ass\\\'y |
| 31 |  |
Anti-loose nut |
| 32 |  |
Impeller |
| 33 |  |
Stator screw |
| 34 |  |
Spring Washer |
| 35 |  |
Flat washer |
| 36 |  |
Axle sleeve |
| 37 |  |
Rear bracket |
| 38 |  |
Stator Ass\\\'y |
| 39 |  |
608 bearing |
| 40 |  |
Armature Ass\\\'y |
| 41 |  |
Bearing |
| 42 |  |
Front support Ass\\\'y |
| 43 |  |
Carbon brush Ass\\\'y |
| 44 |  |
Carbon brush |
| 45 |  |
Copper brush holder |
| 46 |  |
Brush holder bracket |
| 47 |  |
3 in 1 screw |
| 48 |  |
Shaft Ass\\\'y |
| 50 |  |
Flexible shaft |
| 51 |  |
Tube Ass\\\'y |
| 52 |  |
Flexible shaft clip |
| 53 | Connector | |
| 54 | Gear box ass\\\'y | |
| 55 | Retaining collar | |
| 56 | C shape retaining collar | |
| 57 | 6900 bearing | |
| 58 | Washer | |
| 59 | Bevel gear | |
| 60 | Gear box | |
| 61 | Sunk screw | |
| 63 | Washer | |
| 64 | 629Z bearing | |
| 65 | Bevel gear | |
| 66 | Whitney key | |
| 67 | Output shaft | |
| 68 | Bearing 6002-2RS | |
| 69 | Jump ring | |
| 70 | Axle sleeve | |
| 71 | Oil seal | |
| 73 | Sealing sheet | |
| 74 | Hex head screw | |
| 75 | Screw set | |
| 76 | Self-locking nut | |
| 77 | Screw set | |
| 78 | Small safety guard | |
| 79 | 3 in 1 anti-loose screw | |
| 80 | 3 in 1 anti loose screw | |
| 81 | Axle ring | |
| 82 | Blade | |
| 83 | Blade Cover | |
| 84 | Blade press board | |
| 85 | Bell shape washer | |
| 86 | Nut set | |
| 87 | Accessory | |
| 88 | Shoulder belt | |
| 89 | Pin | |
| 90 | Spanner | |
| 91 | Screw | |
| 92 | Self-tapping screw | |
| 93 | Self-tapping screw | |
| 94 | Right housing | |
| 95 | Right volute housing | |
| 96 | Rubber pad Same as POS no. 5 | |
| 97 | 3 in 1 screw Same as POS no.47 |
